ZG2-XC15CR
ZG2-XC15CR ZG2 1013H 257550 OMRON ZG2 Laser Robotic Extension Cable 15m
$0.00USD
4654 kwenye hisa
Vipimo Muhimu
LED (Vipimo):Judgment indicators for each task (indication color: orange): T1, T2, T3, T4Laser indicator (indication color: green): LD_ONZero reset indicator (indication color: green): ZEROTrigger indicators (indication color: green): TRIG
Bidhaa (Vipimo):ZG2-DSU11
Mfano (Vipimo):Measurement object
Matokeo (Vipimo):5 mW max. output, 1 mW max. exposure (without using optical instruments)
Taarifa za Msambazaji
OMRON
Bidhaa: 41472
Kwa kawaida husafirisha ndani ya siku 2-3 za kazi
Ubora Umeheshimiwa
Usafirishaji wa haraka
Msaada wa Kiufundi
Speci ya Kiufundi
| Kipengele | Thamani |
|---|---|
| LED (Vipimo) | Judgment indicators for each task (indication color: orange): T1, T2, T3, T4Laser indicator (indication color: green): LD_ONZero reset indicator (indication color: green): ZEROTrigger indicators (indication color: green): TRIG |
| Bidhaa (Vipimo) | ZG2-DSU11 |
| Mfano (Vipimo) | Measurement object |
| Matokeo (Vipimo) | 5 mW max. output, 1 mW max. exposure (without using optical instruments) |
| Uzito (Vipimo) | Approx. 280 g |
| Onyesho (Vipimo) | LCD monitor |
| RS-232C (Vipimo) | 1 port, 115,200 bps max. |
| Ukadiriaji (Vipimo) | Power supply voltage |
| Nyenzo (Vipimo) | Case: Polycarbonate (PC) |
| Kazi (Vipimo) | No. of logged data5 |
| Vifaa (Vipimo) | Ferrite Core (1 piece), Instruction Manual |
| Azimio (Vipimo) | Height direction1 |
| I/O ya Mfululizo (Vipimo) | USB2.0 |
| Urefu wa Mawimbi (Vipimo) | 658 nm |
| ZG2-WDS3VT (Vipimo) | Omron standard mirrored object |
| Darasa la leza (Vipimo) | Class 2M of EN60825-1 / IEC60825-1Class IIIB of FDA (21CFR 1040.10 and 1040.11) |
| Urefu wa kebo (Vipimo) | 2 m |
| Chanzo cha mwanga (Vipimo) | Type |
| Masafa ya kuonyesha (Vipimo) | -999.99999 to 999.99999 |
| Hali za vichochezi (Vipimo) | External trigger/continuous |
| Kazi kuu (Vipimo) | No. of settings banks |
| Mfumo wa macho (Vipimo) | Diffuse reflective |
| Matokeo sambamba3 (Vipimo) | Output |
| Wasifu uliohifadhiwa (Vipimo) | 16 profiles (1 profile per bank) |
| Kazi zingine (Vipimo) | Alarm output functions |
| Mwelekeo wa upana (Vipimo) | 111 µm(70 mm/631 pixels) |
| (Vipimo na maelezo ya kuagiza) | Order code |
| Unyevu wa mazingira (Vipimo) | Operating and storage: 35% to 85% (with no condensation) |
| Kiolesura cha Nje (Vipimo) | Input/outputsignal lines |
| Aina ya kuingiza/kutoa (Vipimo) | NPN |
| Vipimo (Vipimo) | Height, 2-point Step, 3-point Step, Edge position, Edge width, Angle, Intersection coordinates, Intersection angle, Sectional area(up to eight items can be measured simultaneously) |
| Kiwango cha kipimo (Vipimo) | Height direction |
| Kitengo cha chini cha kuonyesha (Vipimo) | 10 nm |
| Mzunguko wa kipimo2 (Vipimo) | 16 ms (high-precision mode), 8 ms (standard mode), 5 ms (high-speed mode) |
| Kitu cha kipimo (Vipimo) | Surface of non-transparent objects |
| Tafakari ya kawaida (Vipimo) | Diffuse reflective |
| Halijoto ya mazingira (Vipimo) | Operating: 0 to 50°C, Storage: -15 to 60°C (with no icing or condensation) |
| Kazi za msaidizi (Vipimo) | Filter, Laser power adjustment, Position correction (height, position, lope), Linked operation, Point of inflection measurement |
| Matumizi ya sasa (Vipimo) | 0.5 A max. |
| Nguvu ya dielektri (Vipimo) | 1,000 VAC, 50 / 60 Hz for 1 min between lead wires and Controller case |
| NPN (Vipimo na maelezo ya kuagiza) | ZG-RPD11 |
| PNP (Vipimo na maelezo ya kuagiza) | ZG-RPD41 |
| Kiwango cha ulinzi (Vipimo) | IP20 (IEC 60529) |
| Bidhaa (Vipimo na maelezo ya kuagiza) | Order code |
| Jina (Vipimo na maelezo ya kuagiza) | Order code |
| Upinzani wa insulation (Vipimo) | 20 MΩat 250 V between lead wires and Controller case |
| Kadi ya kumbukumbu (256 MB)7 (Vipimo) | Profiles saved: 35,328 profiles max. (256 profiles x 138 files)Measurement values saved: 7,150,000 values max. (65,000 values x 110 files) |
| ZG2-WDS70/WDS22/WDS8T (Vipimo) | Omron standard white alumina ceramic object |
| 128 MB (Vipimo na maelezo ya kuagiza) | F160-N1285 |
| 24 VDC (Vipimo na maelezo ya kuagiza) | NPN |
| 256 MB (Vipimo na maelezo ya kuagiza) | F160-N2565 |
| Marekebisho ya unyeti (Vipimo) | Multi, High-speed multi, Auto, Fixed |
| Vidhibiti vinavyoweza kuunganishwa (Vipimo) | ZG2-WDC11/WDC41 |
| Upinzani wa Mazingira (Vipimo) | Ambient light intensity |
| Uwezo (Vipimo na maelezo ya kuagiza) | Order code |
| Upinzani wa mazingira (Vipimo) | Ambient temperature |
| Kazi za benki za nje (Vipimo) | 4096 |
| Ingizo la kusimamisha leza (LD-OFF) (Vipimo) | ON: O V short or 1.5 V max.OFF: Open (leakage current: 0.1 mA max.) |
| Vitendaji vya kichocheo cha kumbukumbu (Vipimo) | External triggers, data triggers (self-triggers), and time triggers |
| Mwelekeo wa upana (kawaida) (Vipimo) | 70 mm |
| Kwa kitengo 1 (Vipimo na maelezo ya kuagiza) | ZS-XPM1 |
| Aina ya matokeo (Vipimo na maelezo ya kuagiza) | Order code |
| Tabia ya halijoto3 (Vipimo) | 0.02% F.S./°C |
| Ugavi wa umeme (Vipimo na maelezo ya kuagiza) | Output type |
| Idadi ya Vidhibiti Vinavyoweza Kuunganishwa (Vipimo) | 24 |
| Mbinu ya macho (Vipimo na maelezo ya kuagiza) | Sensing distance |
| Upinzani wa mshtuko (uharibifu) (Vipimo) | 150 m/s², 3 times each in 6 directions (up/down, right/left, forward/backward) |
| Idadi ya Vichwa vya Sensor vinavyoweza kuunganishwa (Vipimo) | 1 per Controller |
| Mwelekeo wa urefu (Vipimo na maelezo ya kuagiza) | Width direction |
| Kifaa kinachounganisha (Vipimo na maelezo ya kuagiza) | Order code |
| Kuakisi kwa kueneza (Vipimo na maelezo ya kuagiza) | 50±3 mm |
| Matokeo ya hukumu (YANAYOPITIA YOTE/KOSA) (Vipimo) | NPN open collector30 VDC, 50 mA max.Residual voltage: 1.2 V max. |
| Tafakari ya kawaida (Vipimo na maelezo ya kuagiza) | 22.3±0.5 mm |
| Upinzani wa mtetemo (uharibifu) (Vipimo) | Vibration frequency: 10 to 150 Hz, single amplitude: 0.35 mm, acceleration: 50 m/s² |
| Kebo ya upanuzi ya mita 3 (Vipimo na maelezo ya kuagiza) | ZG2-XC3CR |
| Kebo ya upanuzi ya mita 8 (Vipimo na maelezo ya kuagiza) | ZG2-XC8CR |
| Kwa vitengo 2 au zaidi (Vipimo na maelezo ya kuagiza) | ZS-XPM2 |
| Kebo ya upanuzi ya mita 15 (Vipimo na maelezo ya kuagiza) | ZG2-XC15CR |
| Kebo ya upanuzi ya mita 25 (Vipimo na maelezo ya kuagiza) | ZG2-XC25CR |
| Kitengo cha kiungo cha kidhibiti (Vipimo na maelezo ya kuagiza) | ZS-XCN |
| Matokeo ya hukumu (JUU/PASI/CHINI/KOSA) (Vipimo) | NPN open collector30 VDC, 50 mA max.Residual voltage: 1.2 V max. |
| Mstari (katika mwelekeo wa urefu)2 (Vipimo) | ±0.1% F.S. |
| Kwa muunganisho wa PLC/PT (mita 2) (Vipimo na maelezo ya kuagiza) | ZS-XPT2 |
| Umbo la boriti (katika umbali wa katikati wa kipimo)4 (Vipimo) | 120 µm × 75 mm (typical) |
| Kisawazishi cha kidijitali (kifaa cha kupokezana) (Vipimo na maelezo ya kuagiza) | ZG2-XEQ |
| Kwa muunganisho wa kompyuta binafsi (mita 2) (Vipimo na maelezo ya kuagiza) | ZS-XRS2 |
| Kebo ya muunganisho wa kusawazisha kidijitali ya mita 0.2 (Vipimo na maelezo ya kuagiza) | ZG2-XC02D |
Maelezo ya Bidhaa
ZG2 Laser Cable Robotic Extension 15m
Vipengele Muhimu
- Ubora wa kiwango cha viwanda
- Inaendana na RoHS
- Imethibitishwa CE
- Dhamana ya mwaka 1
Maelezo ya Kiufundi
Optical method
Nyaraka za Bidhaa
Jalada la data
Speci za kiufundi na data ya utendaji
Mwongozo wa Mtumiaji
Mwongozo wa usakinishaji na uendeshaji
