XLG-150-L-AB
XLG-150-L-AB MEANWELL AC-DC Single output LED driver Constant Power Mode with built-in PFC, Output 214VDC / ..
$0.00USD
3772 kwenye hisa
Vipimo Muhimu
Jina (Maelezo):XLG-150-L-AB
Jimbo (Maelezo):New
Hisa (Maelezo):Yes
Muundo (Maelezo):Box
Taarifa za Msambazaji
MEANWELL
Bidhaa: 6448
Kwa kawaida husafirisha ndani ya siku 2-3 za kazi
Ubora Umeheshimiwa
Usafirishaji wa haraka
Msaada wa Kiufundi
Speci ya Kiufundi
| Kipengele | Thamani |
|---|---|
| Jina (Maelezo) | XLG-150-L-AB |
| Jimbo (Maelezo) | New |
| Hisa (Maelezo) | Yes |
| Muundo (Maelezo) | Box |
| Mfululizo (Maelezo) | XLG-150-AB |
| Idhini (Maelezo) | CCC, CE, EAC, ENEC, MM, RCM, UL |
| Nguvu (W) (Maelezo) | 150,00 |
| Regulation (Details) | 0-10V, 1-10V, Resistance 0-100K, PWM Signal 10V |
| Fomu ndogo (Maelezo) | IP67 |
| Upana (mm) (Maelezo) | 63.00 |
| Urefu (mm) (Maelezo) | 35.50 |
| Kiwango cha Juu cha Ingizo la AC (Maelezo) | 305,00 |
| Kiwango cha chini cha kuingiza AC (Maelezo) | 100,00 |
| Maombi (Maelezo) | Lighting, Industrial |
| Mtengenezaji (Maelezo) | MEAN WELL |
| Aina ya bidhaa (Maelezo) | LED Driver |
| Kutengwa (V) (Maelezo) | 4.200,00 |
| Nguvu ya Kilele (W) (Maelezo) | One hundred fifty |
| Kiunganishi cha kuingiza (Maelezo) | Cable |
| Masafa ya kuingiza (Maelezo) | 50 Hz, 60 Hz |
| Muda Mrefu/Usuli (Maelezo) | 180.00 |
| Maelezo Marefu (Maelezo) | LED driver dimmable with constant power.Specially designed for powering LEDs directly in a steady stream.Format in metal box sealedIP67.Input range100-305Vca47-63Hz.Output in constant current700mA.Adjustable by external potentiometer (350-1050mA).Maximum output power rating of betweenSeven hundred-1050mA.Range of output voltage with current mode constant120 to 214Vccaccording to demand load and according to adjustment of the output current.Power:150W.Efficiency typical:93%.Potentiometer:This model incorporates 1 internal potentiometer that allows us to adjust the output current 350-1050mA.Regulation0% to 100% of the output intensity with a slider0-10V / 1-10V,a PWM signal of 10V with a frequency of 100Hz to 3KHz or resistance of 0 to 100K Ohms. With the regulation we can turn off the output, but we need a regulator 0-10V. Regulators 1-10V not arrive to give 0V do not shut down the output.Input class I with grounding.Factor corrector, power>0,95to 230vac at full load.Protection against over loads, short-circuits, over temperature, input voltage high and output voltage.Surge protection:Approved HL Class I Division 2 for ex-zones in the US.Operating temperature range of caseTcfrom-40ºCup+90ºC.Dimensions (Length x Width x Height):180 x 63 x 35.5 mm5 years of warranty.Manufacturer: MEAN WELL.CLICK VIDEO XLG.The series XLG are LED drivers with constant power. Give an output constant current which can be adjusted by the potentiometer and the range of output voltage varies according to the setting of the current. In this way we can get the maximum power output while to adjust to different current values. The sources of constant power offer a wide operating range (voltage + current), allowing to use one model for different applications with different requirements of voltage and current.This source is designed to work directly with leds (plates LED or COBs), not with LED strips. Must be equipment that is fed in a steady stream.This source works on a constant current when we connect the LEDs directly to have a voltage within the range of output voltage mode constant current and a working current equal to the output current.In this version AB, the output current can be adjusted byknob that incorporates the source itself,in addition to having regulation 0-10V/1-10V, 10V PWM, or resistance.The series XLG are LED drivers, class I grounded.With metal housing, waterproof to IP67, the series XLG has a high efficiencyup to 94.5%, and surge protection (6kV / 4kV and 10kV optional) according to the regulations EN61547 and EN61000-4-5, suitable for any application of outdoor luminaires.This L version is designed to work with current ranges between 700-1050mA offering the maximum power output. Are appropriate to projects of general lighting in indoor and outdoor, port applications, street lighting, spaces for horticulture, lighting fixtures, etc, in compliance with the requirements of security at the global level for lighting. Approved HL Class I Division 2 for ex-zones in the US.Can be adjusted by regulatory assets or liabilities0-10Vor1-10V, signal 10V PWM of 100Hz to 3KHz or by resistance of 0 to 100KOhmios. Does not work with dimmers Triac dimmer cutting phase.(Not to be confused with regulators TRIACs, cutting phase. This driver cannot be regular with a Triac).With potentiometers assets that you can give 0V to shut down the output without the need of a switch. Dimmers 1-10V we can only reach 10% of regulation without shutting down the output. If you want to regulate the LED strips we recommend the series PWM.Compatible with any regulator 0-10V or 1-10V-market both assets and liabilities. Some compatible models tested are:MEAN WELL DAP-04S01 (compatible with any push button normally open).SIMON: 75317BJC: 5TC8 425LEGRAND: 0784 04ABB- "NIESSEN": N2260.9SIEMENS: 5TC8424EFAPEL: Model 21210LED BOX: Model LD1160188OSRAM: Model DIM MCUJUNG: Model 240-10We can put about 20 sources for each regulator. The maximum distance is 100 meters between the regulator and the driver. |
| Kiunganishi cha kutoa (Maelezo) | Cable |
| Aina ya Kiingilio CA (Maelezo) | Single-phase |
| Dhamana (Miaka) (Maelezo) | 5,00 |
| Nchi ya Asili (Maelezo) | China |
| Output current mA (Details) | 350, 400, 450, 500, 550, 600, 650, 700, 750, 800, 850, 900, 950, 1000, 1050 |
| Intensity of Minimum Output (mA) (Details) | 350,00 |
| Kiwango cha Upeo wa Pato (mA) (Maelezo) | 1.050,00 |
Maelezo ya Bidhaa
More details
Vipengele Muhimu
- Ubora wa kiwango cha viwanda
- Inaendana na RoHS
- Imethibitishwa CE
- Dhamana ya mwaka 1
Maelezo ya Kiufundi
LED driver dimmable with constant power.
