XLG-150-H-A
XLG-150-H-A MEANWELL AC-DC Single output LED driver Constant Power Mode with built-in PFC, Output 56VDC / 4...
$0.00USD
3128 kwenye hisa
Vipimo Muhimu
Jina (Maelezo):XLG-150-HAS
Jimbo (Maelezo):New
Muundo (Maelezo):Box
Mfululizo (Maelezo):XLG-150-A
Taarifa za Msambazaji
MEANWELL
Bidhaa: 6448
Kwa kawaida husafirisha ndani ya siku 2-3 za kazi
Ubora Umeheshimiwa
Usafirishaji wa haraka
Msaada wa Kiufundi
Speci ya Kiufundi
| Kipengele | Thamani |
|---|---|
| Jina (Maelezo) | XLG-150-HAS |
| Jimbo (Maelezo) | New |
| Muundo (Maelezo) | Box |
| Mfululizo (Maelezo) | XLG-150-A |
| Idhini (Maelezo) | CCC, CE, EAC, ENEC, MM, RCM, UL |
| Nguvu (W) (Maelezo) | 150,00 |
| Fomu ndogo (Maelezo) | IP67 |
| Upana (mm) (Maelezo) | Sixty three |
| Urefu (mm) (Maelezo) | 35.5 |
| Kiwango cha Juu cha Ingizo la AC (Maelezo) | 305,00 |
| Kiwango cha chini cha kuingiza AC (Maelezo) | 100,00 |
| Maombi (Maelezo) | Lighting, Industrial |
| Mtengenezaji (Maelezo) | MEAN WELL |
| Aina ya bidhaa (Maelezo) | LED Driver |
| Kutengwa (V) (Maelezo) | 4.200,00 |
| Nguvu ya Kilele (W) (Maelezo) | One hundred fifty |
| Kiunganishi cha kuingiza (Maelezo) | Cable |
| Masafa ya kuingiza (Maelezo) | 50 Hz, 60 Hz |
| Muda Mrefu/Usuli (Maelezo) | One hundred eighty |
| Maelezo Marefu (Maelezo) | LED driver with constant power output.Specially designed for powering LEDs directly in a steady stream.Format in metal box sealedIP67.Input range100-305Vca47-63Hz.Output in constant current2,8 A.Adjustable by external potentiometer (1,4-4,17 (A).Maximum output power rating of between2,68-4,17 To.Range of output voltage with current mode constant27 to 56Vccaccording to demand load and according to adjustment of the output current.Power:150W.Efficiency typical:92%.Potentiometer:This model incorporates 1 internal potentiometer that allows us to adjust the output current between 0.875 and at 2.78 A.Input class I with grounding.Factor corrector, power>0,95to 230vac at full load.Protection against over loads, short-circuits, over temperature, input voltage high and output voltage.Surge protection:Approved HL Class I Division 2 for ex-zones in the US.Operating temperature range of caseTcfrom-40ºCup+90ºC.Dimensions (Length x Width x Height):180 x 63 x 35.5 mm5 years of warranty.Manufacturer: MEAN WELL.CLICK VIDEO XLG.The series XLG are LED drivers with constant power. Give an output constant current which can be adjusted by the potentiometer and the range of output voltage varies according to the setting of the current. In this way we can get the maximum power output while to adjust to different current values. The sources of constant power offer a wide operating range (voltage + current), allowing to use one model for different applications with different requirements of voltage and current.This source is designed to work directly with leds (plates LED or COBs), not with LED strips. Must be equipment that is fed in a steady stream.This source works on a constant current when we connect the LEDs directly to have a voltage within the range of output voltage mode constant current and a working current equal to the output current.In this version, the output current can be adjusted byknob that incorporates the source itself.The series XLG are LED drivers, class I grounded.With metal housing, waterproof to IP67, the series XLG has a high efficiencyup to 94.5%, and surge protection (6kV / 4kV and 10kV optional) according to the regulations EN61547 and EN61000-4-5, suitable for any application of outdoor luminaires.This version H is designed to give a low output voltage of less than 60V with the maximum possible current, maximum output voltage of 56Vcc. Are appropriate to projects of general lighting in indoor and outdoor, port applications, street lighting, spaces for horticulture, lighting fixtures, etc, in compliance with the requirements of security at the global level for lighting. Approved HL Class I Division 2 for ex-zones in the US. |
| Kiunganishi cha kutoa (Maelezo) | Cable |
| Aina ya Kiingilio CA (Maelezo) | Single-phase |
| Dhamana (Miaka) (Maelezo) | 5,00 |
| Nchi ya Asili (Maelezo) | China |
| Output current mA (Details) | 1400, 1450, 1500, 1550, 1600, 1650, 1700, 1750, 1800, 1850, 1900, 1950, 2000, 2050, 2100, 2200, 2250, 2300, 2400, 2450, 2500, 2600, 2700, 2800, 2900, 3000, 3100, 3200, 3300, 3400, 3500, 4000, 4500 |
| Intensity of Minimum Output (mA) (Details) | 1.400,00 |
| Kiwango cha Upeo wa Pato (mA) (Maelezo) | 4.170,00 |
Maelezo ya Bidhaa
More details
Vipengele Muhimu
- Ubora wa kiwango cha viwanda
- Inaendana na RoHS
- Imethibitishwa CE
- Dhamana ya mwaka 1
Maelezo ya Kiufundi
LED driver with constant power output.
Nyaraka za Bidhaa
Jalada la data
Speci za kiufundi na data ya utendaji
Mwongozo wa Mtumiaji
Mwongozo wa usakinishaji na uendeshaji
