TC-2KS40-AI16-EX2-PR-CSTM
TC-2KS40-AI16-EX2-PR-CSTM 2905931 PHOENIX CONTACT Termination Carrier for connecting 16 MACX Analog Ex i sig..
$0.00USD
3763 kwenye hisa
Vipimo Muhimu
:33 V AC (2 A)
Fuse:2x 2.5 A on PCB, slow-blow (replaceable)
Kina:160 mm
Mshtuko:15g, according to IEC˽60068-2-27
Taarifa za Msambazaji
Bidhaa: 0
Kwa kawaida husafirisha ndani ya siku 2-3 za kazi
Ubora Umeheshimiwa
Usafirishaji wa haraka
Msaada wa Kiufundi
Speci ya Kiufundi
| Kipengele | Thamani |
|---|---|
| 33 V AC (2 A) | |
| Fuse | 2x 2.5 A on PCB, slow-blow (replaceable) |
| Kina | 160 mm |
| Mshtuko | 15g, according to IEC˽60068-2-27 |
| Upana | 322 mm |
| Urefu | ≤ 2000 m |
| Jumla | For proper use, the specifications of the installation directive (see Downloads) must be observed. For applications or use with third-party products, the specifications, and the safety and warning instructions of the respective third-party manufacturer must also be met. |
| Insulation | Basic insulation |
| Jina la matokeo | Switching output |
| Aina ya bidhaa | Module carrier |
| Ingizo la sasa | ≤ 2 A |
| Aina ya kupachika | DIN rail mounting |
| Utambulisho | UL 61010 Listed |
| Onyesho la hali | 2x green LEDs (PWR1 and PWR2) |
| Kiwango cha uchafuzi wa mazingira | 2 |
| Ugavi usiohitajika | yes, decoupled from diodes |
| Urefu wa kukatwa | 7 mm |
| Mbinu ya muunganisho | Screw connection |
| Nafasi ya kupachika | vertical, horizontal |
| Kadi ya I/O inayofaa | NFAI143 |
| Volti ya kawaida ya Umoja wa Mataifa | < 50 V DC (Per signal/channel) |
| Idadi ya nafasi | 6 |
| Volti ya kuongezeka iliyokadiriwa | 0.5 kV |
| Kiwango cha ulinzi | IP00 |
| Kategoria ya volteji nyingi | III |
| Maagizo ya kusanyiko | No end clamp |
| Idadi ya miunganisho | 1 |
| Viwango/kanuni | DIN EN 50178 |
| Mtetemo (uendeshaji) | 2g, according to IEC 60068-2-6 |
| Aina ya ubadilishaji wa mguso | 1 N/C contact (alarm = open) |
| Mkondo wa juu unaoruhusiwa | 1 A (Signal/channel) |
| Volti ya insulation iliyokadiriwa | 50 V |
| Volti ya juu zaidi ya kubadili | 30 V DC (2 A) |
| Sehemu ya msalaba ya kondakta AWG | 24 ... 12 |
| Sehemu ngumu ya kondakta | 0.14 mm² ... 2.5 mm² |
| Halijoto ya mazingira (uendeshaji) | -20 °C ... 70 °C (For use at an ambient temperature of up to 70°C: the MACX MCR-SL-RPSSI-2I modules must be mounted 5 mm apart. Use the CLIPFIX 35-5 end brackets provided as spacers.) |
| Sehemu ya msalaba ya kondakta inayonyumbulika | 0.14 mm² ... 2.5 mm² |
| Unyevu unaoruhusiwa (uendeshaji) | 5 % ... 95 % (non-condensing) |
| Upolarization na ulinzi wa mawimbi | Yes |
| Ukadiriaji wa kuwaka kulingana na UL 94 | V0 |
| Halijoto ya kawaida (uhifadhi/usafiri) | -40 °C ... 80 °C (Please observe module specifications) |
Maelezo ya Bidhaa
More details
Vipengele Muhimu
- Ubora wa kiwango cha viwanda
- Inaendana na RoHS
- Imethibitishwa CE
- Dhamana ya mwaka 1
