SAC-5P-M12MSL/ 1,5-280 FE SH
SAC-5P-M12MSL/ 1,5-280 FE SH 1414884 PHOENIX CONTACT Power cable
$0.00USD
4009 kwenye hisa
Vipimo Muhimu
:in accordance with DIN EN 50267-2-1
Aina:Plug straight M12
Usimbaji:L
Imehifadhiwa:yes
Taarifa za Msambazaji
Bidhaa: 0
Kwa kawaida husafirisha ndani ya siku 2-3 za kazi
Ubora Umeheshimiwa
Usafirishaji wa haraka
Msaada wa Kiufundi
Speci ya Kiufundi
| Kipengele | Thamani |
|---|---|
| in accordance with DIN EN 50267-2-1 | |
| Aina | Plug straight M12 |
| Usimbaji | L |
| Imehifadhiwa | yes |
| Aina ya kebo | PUR halogen-free gray [280] |
| Maombi | Power supply |
| Aina ya usimbaji | L (Power) |
| Urefu wa kebo | 1.5 m |
| Uzito wa kebo | 202 kg/km |
| Haina halojeni | in accordance with DIN VDE 0472 part 815 |
| Aina ya bidhaa | Power cable |
| Volti ya majaribio | ≥ 3000 V AC (Spark test) |
| Mtindo wa UL AWM | 20233 / 10493 (80°C/300 V) |
| Marekebisho ya makala | 06 |
| Nyenzo ya mawasiliano | CuZn |
| Upinzani wa moto | According to UL 758/1581 (Cable Flame) |
| Upinzani mwingine | Hydrolysis and microbe resistant as per VDE 0282 section 10 |
| Upinzani dhidi ya mafuta | according to DIN EN 60811-404, 168 h at 100 °C |
| Nyenzo ya kondakta | Bare Cu litz wires |
| Mkondo wa nominella IN | 16 A |
| Volti ya kawaida ya Umoja wa Mataifa | 63 V DC |
| Waya moja, rangi | brown, white, blue, black, pink |
| Kiwango cha uchafuzi wa mazingira | 3 |
| Mchoro wa vipimo | |
| Idadi ya nafasi | 5 |
| Kiwango cha ulinzi | IP65 |
| Idadi ya soketi za kebo | 1 |
| Kategoria ya volteji nyingi | III |
| Uteuzi wa kawaida | M12 connector |
| Upinzani wa insulation | ≥ 100 MΩ |
| Nyenzo ya mwili wa mshiko | PP |
| Unene, insulation | ≥ 0.31 mm |
| Ala ya nje, rangi | gray RAL 7001 |
| Volti ya kawaida, kebo | ≤ 300 V AC |
| Ala ya nje, nyenzo | PUR |
| Sehemu ya msalaba ya kondakta | 5x 2.5 mm² |
| Kipenyo cha kebo ya nje | 10.40 mm ±0.3 mm |
| Unene, ala ya nje | approx. 0.76 mm |
| Nyenzo za mawasiliano | PA |
| Nyenzo ya uso wa mguso | Ni/Au |
| Uzuiaji wa waya wa nyenzo | PP |
| Viwango/vipimo | IEC 61076-2-111 |
| Upinzani wa juu zaidi wa kondakta | ≤ 8 Ω/km (at 20 °C) |
| Mizunguko ya kuingiza/kutoa | ≥ 100 |
| Nyenzo ya kuunganisha skrubu | Zinc die-cast, nickel-plated |
| Kipenyo cha waya ikijumuisha insulation | 2.85 mm ±0.1 mm |
| Halijoto ya mazingira (uendeshaji) | -50 °C ... 80 °C (cable, fixed installation) |
| Uwezo wa mzigo unaobadilika (kuinama) | Max. bending cycles: 5000000, Bending radius: 10 x D, Traversing path: 10 m, Traversing rate: 3 m/s, Acceleration: 10 m/s² |
| Ukadiriaji wa kuwaka kulingana na UL 94 | V0 |
| Kiwango cha chini cha kuinama, usakinishaji usiobadilika | 5 x D |
| Radi ndogo zaidi ya kupinda, usakinishaji usiobadilika | 52 mm |
| Kiwango cha chini cha kuinama, usakinishaji rahisi | 10 x D |
| Radi ndogo zaidi ya kupinda, usakinishaji unaoweza kusongeshwa | 104 mm |
Maelezo ya Bidhaa
Power cable, 5-pole halogen-free, shielded (Advanced Shielding Technology), Straight M12 connector, coding: L, to free cable end, cable length: 1.5 m, for direct current up to 16 A / 63 V
Vipengele Muhimu
- Ubora wa kiwango cha viwanda
- Inaendana na RoHS
- Imethibitishwa CE
- Dhamana ya mwaka 1
