PCD-25-700A
PCD-25-700A MEANWELL AC-DC Single output LED driver Constant Current (CC), Input 90-135VAC, Output 0.7A / 24..
$0.00USD
3915 kwenye hisa
Vipimo Muhimu
Jina:PCD-25-700A
Muundo:Box
Mfululizo:PCD-25
Kufifia:Triac
Taarifa za Msambazaji
MEANWELL
Bidhaa: 6448
Kwa kawaida husafirisha ndani ya siku 2-3 za kazi
Ubora Umeheshimiwa
Usafirishaji wa haraka
Msaada wa Kiufundi
Speci ya Kiufundi
| Kipengele | Thamani |
|---|---|
| Jina | PCD-25-700A |
| Muundo | Box |
| Mfululizo | PCD-25 |
| Kufifia | Triac |
| Idhini | UL |
| Nguvu (W) | 25,20 |
| Fomu ndogo | IP42 |
| Upana (mm) | 57.00 |
| Urefu (mm) | 29.50 |
| Kiwango cha juu cha kuingiza AC | 135,00 |
| Kiwango cha chini cha kuingiza AC | 90,00 |
| Maombi | Lighting |
| Mtengenezaji | MEAN WELL |
| Aina ya bidhaa | LED Driver |
| Kutengwa (V) | 3.750,00 |
| Nguvu ya Kilele (W) | 25.2 |
| Kiunganishi cha kuingiza data | Cable |
| Masafa ya kuingiza | 50 Hz, 60 Hz |
| Muda Mrefu/Usuli | 84.00 |
| Maelezo Marefu | LED driver dimmable.Specially designed for powering LEDs directly in a steady stream.Format in plastic boxIP42.Input range90-135Vca47-63Hz.Output in constant current700mA.Range of output voltage24 to 36Vccaccording to demand load.Power:25,2 WEfficiency typical:81%.AdjustablebyTriac.Input class II without grounding.Factor corrector, power>0,9to 230vac at full load.Operating temperature range of caseTcfrom-35ºCup+60ºC.Dimensions (Length x Width x Height):84 x 57 x 29.5 mm3 years of warranty.Manufacturer: MEAN WELL.The series PCD are LED drivers designed to work directly with leds (plates LED or COBs), not with LED strips. Must be equipment that is fed in a steady stream. With plastic housing designed for lighting applications in interior.Can be controlled via TRIACs (regulators that cut the voltage input). See the list of Triacs supported in the technical data sheet.(Not to be confused with dimmers 1-10V. This driver not only can be adjusted by Triac. Check that your dimmer is a Triac, it must have a Line input and a Line Output for connecting to the driver, not an output 1-10V).Protection against excess temperature and short circuit.Tests burn-in (burn-in test) at 100% load. Have a low cost and a high reliability. |
| Kiunganishi cha kutoa | Cable |
| Aina ya Kiingilio CA | Single-phase |
| Dhamana (Miaka) | 3,00 |
| Nchi ya Asili | China |
| Mkondo wa kutoa mA | Seven hundred |
| Kiwango cha Chini cha Pato (mA) | 700,00 |
| Kiwango cha Upeo wa Pato (mA) | 700,00 |
Maelezo ya Bidhaa
More details
Vipengele Muhimu
- Ubora wa kiwango cha viwanda
- Inaendana na RoHS
- Imethibitishwa CE
- Dhamana ya mwaka 1
Maelezo ya Kiufundi
LED driver dimmable.
