NBC-M12MRD/4,5-93C/M 8MS 3X4
NBC-M12MRD/4,5-93C/M 8MS 3X4 1484404 PHOENIX CONTACT Network cable (100 MBit/s), PROFINET (100 MBit/s), Ethe..
$57.37USD
211 kwenye hisa
Vipimo Muhimu
:EtherCAT®, 100 MBit/s
aina:Angled Male M12 / IP67
Kifupi:2YH(ST)C11Y
Kunyunyizia:2.1 dB (at 1 MHz)
Taarifa za Msambazaji
Bidhaa: 0
Kwa kawaida husafirisha ndani ya siku 2-3 za kazi
Ubora Umeheshimiwa
Usafirishaji wa haraka
Msaada wa Kiufundi
Speci ya Kiufundi
| Kipengele | Thamani |
|---|---|
| EtherCAT®, 100 MBit/s | |
| aina | Angled Male M12 / IP67 |
| Kifupi | 2YH(ST)C11Y |
| Kunyunyizia | 2.1 dB (at 1 MHz) |
| Muda wa utekelezaji | 5.3 ns/m |
| Nyenzo | CuSn (Contact) |
| Imehifadhiwa | Yes |
| Kulinda | Aluminium coated film, braided tinned copper wires |
| Mfumo wa basi | Ethernet |
| Aina ya Kebo | PROFINET CAT5 energy chain |
| Rangi ya mshiko | black |
| Maombi | Standard |
| Redi ya kupinda | 100 mm |
| Uzito wa Mstari | 61 kg/km |
| Kuongeza kasi | 4 m/s² |
| Urefu wa Kebo | 4.5 m |
| Haina halojeni | Yes |
| Idadi ya nguzo | 4 |
| Aina ya Bidhaa | Packaged data cable |
| Kasi ya mawimbi | 0.66 c |
| Aina ya Usimbaji | D (Data) |
| Kufunga kamba kamili | Quadruple star |
| Upinzani wa Mafuta | in accordance with DIN EN 60811-2-1 |
| Mstari wa Ishara wa AWG | 22 |
| Muundo wa kebo | 1x4xAWG22/7, SF/TQ |
| Upinzani wa Moto | according to IEC 60332-1-2 |
| Upinzani wa Misa | ≤ 5 mΩ |
| Upinzani Mwingine | UV-resistant |
| Imekadiriwa Sasa IN | 4 A |
| Volti iliyokadiriwa UN | 30 V AC |
| Vipengele maalum | Electrical characteristics according to EN 50288-2-2 |
| Kuripoti Hali | no |
| Nguvu ya mvutano | ≤ 150 N |
| Mkazo wa torsional | ± 30°/m |
| Upinzani wa kujamiiana | ≤ 20.00 mΩ/m (with 10 MHz) |
| Kasi ya kuweka nafasi | 4 m/s |
| Kukaza torque | 0.4 Nm |
| Nyenzo ya kondakta | Tinned Cu wire |
| Mizunguko ya ujanja | ≥ 100 |
| Kiharusi cha kuweka nafasi | 10 m |
| Volti Iliyokadiriwa na Kebo | 600 V (UL Rating) |
| Kiwango cha uchafuzi wa mazingira | 3 |
| Mchoro wa Vipimo | |
| Ala ya nje, rangi | green RAL 6018 |
| Ufafanuzi wa Kawaida | M8 connector |
| Njia ya maambukizi | copper |
| Kiwango cha ulinzi | IP67 |
| Aina/Kategoria ya Ishara | PROFINET, 100 MBit/s |
| Upinzani wa Insulation | ≥ 100 MΩ |
| Ala ya ndani ya nyenzo | FRNC |
| Viwango/Kanuni | IEC 61076-2-104 |
| Kifuniko cha Kinga cha Macho | 85 % |
| Ala ya Nje, Nyenzo | WHILE |
| Sehemu ya msalaba ya kondakta | 4x 0.34 mm² |
| Kondakta mmoja, rangi | white, yellow, blue, orange |
| Upinzani wa jozi iliyopotoka | ≤ 120,00 Ω/km |
| Kizuizi cha Tabia | 100 Ω ±15 Ω (with 1 .... 100 MHz) |
| Kipenyo cha Nje cha Kondakta | 6.5 mm ±0.2 mm |
| Idadi ya mizunguko ya kupinda | 3000000 |
| Nyenzo ya kuhami waya | PE |
| Volti ya Jaribio la Waya/Ngao | 2000 V (50 Hz, 1 min.) |
| Aina ya kebo (kifupisho) | 93C |
| Volti ya majaribio ya waya kwa waya | 2000 V (50 Hz, 1 min.) |
| Upinzani wa insulation ya mstari | ≥ 500 MΩ*km |
| Dalili ya Hali Inayopatikana | no |
| Unene wa ukuta wa ala ya nje | ca. 0.9 mm |
| Radi ya chini kabisa ya kupinda, isiyobadilika | 5 x D |
| Upunguzaji wa sauti kwa kutumia parafoniki (INAYOFUATA) | 80 dB (with 1 MHz) |
| Halijoto ya mazingira (inayofanya kazi) | -25 °C ... 90 °C |
| Muundo wa Kondakta wa Ishara ya Mstari | 7x 0.25 mm |
| Kiwango cha chini cha kupinda, kinachonyumbulika | 7.5 x D |
| Kipenyo cha waya chenye ala ya kuhami joto | 1.5 mm |
Maelezo ya Bidhaa
Network cable (100 Mbit/s), PROFINET (100 Mbit/s), EtherCAT® (100 Mbit/s), 4-pin halogen-free, shielded (Advanced Shielding Technology), Angled Male M12, coding: D / IP67, on Straight Male M8, coding:
Vipengele Muhimu
- Ubora wa kiwango cha viwanda
- Inaendana na RoHS
- Imethibitishwa CE
- Dhamana ya mwaka 1
