NBC-M12MRD/ 1,0-93E/R4AC
NBC-M12MRD/ 1,0-93E/R4AC 1415264 PHOENIX CONTACT Network Cable NBC-M12MRD/ 1,0-93E/R4AC 1415264
$0.00USD
4730 kwenye hisa
Vipimo Muhimu
:Ethernet CAT5 (TIA 568B:2001)
Aina:Plug angled M12
Nyenzo:CuZn (Contact)
Imehifadhiwa:yes
Taarifa za Msambazaji
Bidhaa: 0
Kwa kawaida husafirisha ndani ya siku 2-3 za kazi
Ubora Umeheshimiwa
Usafirishaji wa haraka
Msaada wa Kiufundi
Speci ya Kiufundi
| Kipengele | Thamani |
|---|---|
| Ethernet CAT5 (TIA 568B:2001) | |
| Aina | Plug angled M12 |
| Nyenzo | CuZn (Contact) |
| Imehifadhiwa | yes |
| Mfumo wa basi | Ethernet |
| Aina ya kebo | Ethernet flexible CAT5, 2-pair [93E] |
| Aina ya vitambuzi | Ethernet |
| Urefu wa kebo | 0.96 m |
| Uzito wa kebo | 42 kg/km |
| Haina halojeni | according to IEC 60754-1 |
| Aina ya bidhaa | Data cable preassembled |
| Mtindo wa UL AWM | 20963 (80°C/30 V) |
| Mzunguko wa jumla | Two pairs with two fillers to the core |
| Jozi zilizopinda | 2 cores to the pair |
| Uwezo wa kebo | approx. 45 nF/km (at 1 kHz) |
| Muda wa utekelezaji wa ishara | 5.3 ns/m |
| Kizuizi cha wimbi | 100 Ω ±5 Ω (at 100 MHz) |
| Mstari wa ishara wa AWG | 26 |
| Upinzani wa kitanzi | ≤ 290.00 Ω/km |
| Upinzani wa moto | according to IEC 60332-1-2 |
| Nguvu ya mvutano | ≤ 80 N |
| Upinzani dhidi ya mafuta | in accordance with EN 60811-2-1 |
| Nyenzo ya kondakta | Bare Cu litz wires |
| Volti ya kawaida ya Umoja wa Mataifa | 48 V AC |
| Upunguzaji wa ngao | 3.2 dB (with 1 MHz) |
| Waya moja, rangi | white/orange-orange, white/green-green |
| Muundo wa kondakta | 2x2xAWG26/7, SF/UTP |
| Upinzani wa kuunganisha | ≤ 100.00 mΩ/m (at 10 MHz) |
| Kiwango cha uchafuzi wa mazingira | 3 |
| Mchoro wa vipimo | |
| Idadi ya nafasi | 4 |
| Njia ya maambukizi | Copper |
| Kiwango cha ulinzi | IP67/IP20 |
| Idadi ya soketi za kebo | 1 |
| Kategoria ya volteji nyingi | I |
| Aina/kategoria ya ishara | Ethernet CAT5 (IEC 11801:2002) |
| Upinzani wa insulation | ≥ 500 MΩ*km |
| Ala ya nje, rangi | water blue RAL 5021 |
| Volti ya kawaida, kebo | ≤ 100 V (Peak value, not for high-power applications) |
| Ala ya nje, nyenzo | PUR |
| Kiini/Kiini cha volteji cha jaribio | 700 V (50 Hz, 1 min.) |
| Sehemu ya msalaba ya kondakta | 2x 2x 0.14 mm² |
| Kipenyo cha kebo ya nje | 6.40 mm ±0.2 mm |
| Kifuniko cha ngao ya macho | 70 % |
| Upunguzaji wa marejesho (RL) | 23 dB (at 4 МHz) |
| Unene, ala ya nje | 1.20 mm |
| Uzuiaji wa waya wa nyenzo | Foamed PE |
| Kiini/Ngao ya Volti ya Jaribio | 700.00 V (50 Hz, 1 min.) |
| Mizunguko ya kuingiza/kutoa | ≥ 100 |
| Viwango/kanuni za waya | Electrical requirements EN 50288-2-2 |
| Kipenyo cha waya ikijumuisha insulation | 0.98 mm |
| Halijoto ya mazingira (uendeshaji) | -40 °C ... 80 °C (cable, fixed installation) |
| Mstari wa ishara ya muundo wa kondakta | 7x 0.16 mm |
| Halijoto ya kawaida (usakinishaji) | -20 °C ... 80 °C |
| Uwezo wa kubeba kebo kwa sasa | 2.00 A (according to DIN VDE 0891-1) |
| Upunguzaji wa mazungumzo ya karibu (INAYOFUATA) | 65.3 dB (with 1 MHz) |
| Ukadiriaji wa kuwaka kulingana na UL 94 | V2 |
| Sifa za upitishaji (kitengo) | CAT5 (IEC 11801:2002) |
| Kiwango cha chini cha kuinama, usakinishaji usiobadilika | 4 x D |
| Radi ndogo zaidi ya kupinda, usakinishaji usiobadilika | 26 mm |
| Kiwango cha chini cha kuinama, usakinishaji rahisi | 8 x D |
| Radi ndogo zaidi ya kupinda, usakinishaji unaoweza kusongeshwa | 52 mm |
| Upunguzaji wa mazungumzo ya karibu na mwisho kwa kutumia nguvu (PSNEXT) | 62.3 dB (with 1 MHz) |
Maelezo ya Bidhaa
Network cable, Ethernet CAT5, Ethernet CAT5, 4-position, PUR halogen-free, water blue RAL 5021, shielded, Plug angled M12, on Plug straight RJ45, cable length: 0.96 m
Vipengele Muhimu
- Ubora wa kiwango cha viwanda
- Inaendana na RoHS
- Imethibitishwa CE
- Dhamana ya mwaka 1
