MSTB 2,5/18-ST AU
MSTB 2,5/18-ST AU 1717013 PHOENIX CONTACT Connector for printed circuit board, nominal current: 12 A, voltag..
$0.00USD
3416 kwenye hisa
Vipimo Muhimu
EAN:Four trillion forty six billion three hundred fifty six million one hundred thirty seven thousand five hundred forty six
Mpangilio muhimu:One million seven hundred seventeen thousand thirteen
Uuzaji wa funguo:AAAFAA -
Kitengo cha kufungasha:50 pcs
Taarifa za Msambazaji
Bidhaa: 0
Kwa kawaida husafirisha ndani ya siku 2-3 za kazi
Ubora Umeheshimiwa
Usafirishaji wa haraka
Msaada wa Kiufundi
Speci ya Kiufundi
| Kipengele | Thamani |
|---|---|
| EAN | Four trillion forty six billion three hundred fifty six million one hundred thirty seven thousand five hundred forty six |
| Mpangilio muhimu | One million seven hundred seventeen thousand thirteen |
| Uuzaji wa funguo | AAAFAA - |
| Kitengo cha kufungasha | 50 pcs |
| UNSPSC 11 (ETIM) | Thirty nine million one hundred twenty one thousand four hundred nine |
| ETIM 3.0 (eCl@ss) | EC001121 |
| ETIM 4.0 (eCl@ss) | EC002638 |
| ETIM 5.0 (eCl@ss) | EC002638 |
| ETIM 6.0 (eCl@ss) | EC002638 |
| UNSPSC 13.2 (ETIM) | Thirty nine million one hundred twenty one thousand four hundred nine |
| UNSPSC 6.01 (ETIM) | Thirty million two hundred eleven thousand eight hundred ten |
| UNSPSC 12.01 (ETIM) | Thirty nine million one hundred twenty one thousand four hundred nine |
| UNSPSC 7.0901 (ETIM) | Thirty nine million one hundred twenty one thousand four hundred nine |
| eCl@ss 4.0 (Ukadiriaji) | 272607xx |
| eCl@ss 4.1 (Ukadiriaji) | Twenty seven million two hundred sixty thousand seven hundred one |
| eCl@ss 5.0 (Ukadiriaji) | Twenty seven million two hundred sixty thousand seven hundred one |
| eCl@ss 5.1 (Ukadiriaji) | Twenty seven million two hundred sixty thousand seven hundred one |
| eCl@ss 6.0 (Ukadiriaji) | Twenty seven million two hundred sixty thousand seven hundred four |
| eCl@ss 7.0 (Ukadiriaji) | Twenty seven million four hundred forty thousand four hundred two |
| eCl@ss 8.0 (Ukadiriaji) | Twenty seven million four hundred forty thousand three hundred nine |
| eCl@ss 9.0 (Ukadiriaji) | Twenty seven million four hundred forty thousand three hundred nine |
| Kufuli (Biashara ya data) | without |
| Kiasi cha chini cha oda | 50 pcs |
| Hatua (Takwimu ya kibiashara) | 5 mm |
| (Hali ya mazingira) | |
| Uchunguzi (Mtazamo wa uwezo) | According to WEEE/RoHS, without filaments according to IEC 60068-2-82/JEDEC JESD 201 |
| Ufupisho (Takwimu ya kibiashara) | Plug-in connector for plate circ. printed |
| Uzi wa skrubu (Taarifa ya kibiashara) | M3 |
| Hatua (Data ya nyenzo - makazi) | 5 mm |
| Mfumo wa programu-jalizi (Data ya kibiashara) | CLASSIC COMBICON |
| Wastani (Data ya nyenzo - makazi) | 85 mm |
| Mguso wa nyenzo (Mguso wa uwezo) | Cu alloy |
| Idadi ya nguzo (Takwimu za kibiashara) | Eighteen |
| Imekadiriwa (Sifa za makala) | 12 To |
| Aina ya mawasiliano (Taarifa ya kibiashara) | Female connection |
| Uzito wa kitengo (bila kujumuisha kifungashio) | 29,473 g |
| Idadi ya sakafu (Takwimu za kibiashara) | One |
| Kutengwa (Data ya nyenzo - mawasiliano) | PA |
| Familia ya makala (Takwimu za kibiashara) | MSTB 2,5/..-ST |
| Aina ya muunganisho (Biashara ya data) | Connection by screw with capsule-traction |
| Idadi ya uwezekano (Takwimu za kibiashara) | Eighteen |
| Upana [w] (Data ya nyenzo - makazi) | 90 mm |
| Urefu [ h ] (Data ya nyenzo - makazi) | 15 mm |
| Urefu [l] (Data ya nyenzo - makazi) | 18,2 mm |
| Aina ya kifungashio (Vipimo vya bidhaa) | packaged in box |
| Idadi ya miunganisho (Takwimu ya kibiashara) | Eighteen |
| Diagram (Lines of flight and air spaces) | |
| Vitengo vya Ufungashaji wa Uteuzi (Vipimo vya Bidhaa) | Units |
| Sifa za uso (Uwezo wa koni) | Coating selective |
| Urefu wa kung'oa (Tabia ya data ya umeme) | 7 mm |
| Umbo la kichwa cha kiendeshi cha skrubu (Takwimu ya kibiashara) | Lengthwise slot (L) |
| Kukaza torque (Tabia ya data ya umeme) | 0.5 Nm ... 0.6 Nm |
| Nyenzo za kuhami joto za kikundi (Data ya nyenzo - mgusano) | I |
| Halijoto ya chumba (huduma) (Dalili za kufungasha) | -40 °C (in function of the curve derating) |
| CTI kulingana na IEC 60112 (Data ya nyenzo - mawasiliano) | Six hundred |
| Halijoto ya kawaida (mkusanyiko) (Dalili za kufungasha) | -5 °C ... 100 °C |
| Eneo la uso wa metali la mguso (safu ya juu) (Koni ya uwezo) | Gold (0,8 - 1,4 µm Au) |
| Sehemu ya kondakta imara (Data ya sifa ya umeme) | 0,2 mm2 ... 2.5 mm2 |
| Kipimo cha axb ya kiume / Kipenyo (Kielelezo cha data ya umeme) | 2.8 mm x 2.0 mm/2.4 mm |
| Muundo wa volteji ya muda mfupi (III/2) (Sifa za makala) | 4 kV |
| Muundo wa kutenganisha volteji (III/2) (Sifa za makala) | 320 V |
| Metal surface area of contact (middle layer) (Ability conex.) | Nickel (2 - 4 ám Ni), |
| Sehemu ya kondakta inayonyumbulika (Data ya sifa ya umeme) | 0,2 mm2 ... 2.5 mm2 |
| Group insulating material (Connection and method of connection) | I |
| Specification of the test (Connection and method of connection) | DIN EN 60664-1 (VDE 0110-1):2008-01 |
| Sehemu ya kondakta AWG / kcmil (Data ya sifa ya umeme) | 24 ... 12 |
| Halijoto ya kawaida (uhifadhi/usafirishaji) (Dalili za kufungasha) | -40 °C ... 70 °C |
| Daraja la kuwaka kulingana na UL 94 (Data ya nyenzo - mawasiliano) | V0 |
| Uso wa metali wa ncha ya embornaje (safu ya juu) (Koni ya uwezo) | Tin (2 - 4 µm Sn) |
| Transient voltage design (II/2) (Connection and method of connection) | 4 kV |
| Voltage isolation design (II/2) (Connection and method of connection) | 630 V |
| Transient voltage design (III/2) (Connection and method of connection) | 4 kV |
| Transient voltage design (III/3) (Connection and method of connection) | 4 kV |
| Voltage isolation design (III/2) (Connection and method of connection) | 320 V |
| Voltage isolation design (III/3) (Connection and method of connection) | 250 V |
| Kondakta 2 zenye sehemu sawa, ngumu (Tabia ya data ya umeme) | 0,2 mm2 ... 1 mm2 |
| Viendeshaji 2 vyenye sehemu sawa, vinavyonyumbulika (Tabia ya data ya umeme) | 0,2 mm2 ... 1.5 mm2 |
| Urefu wa jengo (urefu bila shank ya soldering) (Data ya nyenzo - makazi) | 15 mm |
| Halijoto ya kuwasha ya nyuzi GWIT kulingana na en 60695-2-13 (Data ya nyenzo - mawasiliano) | Seven hundred seventy five |
| Idadi ya uwezo wa kuwaka wa nyuzi GWFI kulingana na en 60695-2-12 (Data ya nyenzo - mawasiliano) | Eight hundred fifty |
| Sehemu ya kondakta inayonyumbulika yenye kidole cha mguu, yenye insulation iliyofunikwa (Kielelezo cha data cha sifa) | 0.25 mm2 ... 2.5 mm2 |
| Sehemu ya kondakta inayonyumbulika yenye kofia ya vidole, bila kifuniko cha plastiki (Kielelezo cha data cha sifa) | 0.25 mm2 ... 2.5 mm2 |
| Jaribio la halijoto la ugumu wa mipira kulingana na en 60695-10-2 (Data ya nyenzo - mawasiliano) | 125 °C |
| Viendeshaji 2 vyenye sehemu sawa, vinavyonyumbulika na AEH bila kifuniko cha plastiki (Kielelezo cha data ya umeme) | 0.25 mm2 ... 1 mm2 |
| Viendeshaji 2 vyenye sehemu sawa, vinavyonyumbulika na TWIN-AEH vyenye kifuniko cha plastiki (Kielelezo cha data cha sifa) | 0.5 mm2 ... 1.5 mm2 |
Maelezo ya Bidhaa
Connector for printed circuit board, nominal section: 2.5 mm², color: green, rated current: 12 A, sizing voltage (III/2): 320 V, surface contacts: Gold, contact type: Connection female, Number of pote
Vipengele Muhimu
- Ubora wa kiwango cha viwanda
- Inaendana na RoHS
- Imethibitishwa CE
- Dhamana ya mwaka 1
Maelezo ya Kiufundi
Connector for printed circuit board, nominal current: 12 A, voltage and sizing (III/2): 320 V, number of poles: 18, pitch: 5 mm, type of connection: Connection by screw with capsule-wheel drive, color: green, surface, contacts: Gold
