MPM-20-5
MPM-20-5 MEANWELL AC-DC Single output Medical Encapsulated power supply, Output 5VDC / 4A, PCB through hole,..
$0.00USD
4211 kwenye hisa
Vipimo Muhimu
Jina:MPM-20-5
Jimbo:New
Muundo:For Printed Circuit
Mfululizo:MPM-20
Taarifa za Msambazaji
MEANWELL
Bidhaa: 6448
Kwa kawaida husafirisha ndani ya siku 2-3 za kazi
Ubora Umeheshimiwa
Usafirishaji wa haraka
Msaada wa Kiufundi
Speci ya Kiufundi
| Kipengele | Thamani |
|---|---|
| Jina | MPM-20-5 |
| Jimbo | New |
| Muundo | For Printed Circuit |
| Mfululizo | MPM-20 |
| Idhini | EC, EAC, EN60601 3rd Edition, UL |
| Nguvu (W) | 20,00 |
| Fomu ndogo | Encapsulated |
| Upana (mm) | 27.20 |
| Urefu (mm) | 52.40 |
| Kiwango cha juu cha kuingiza AC | 264,00 |
| Kiwango cha chini cha kuingiza AC | 80,00 |
| Maombi | Industrial, Medical, Telecommunications |
| Mtengenezaji | MEAN WELL |
| Aina ya bidhaa | Power supply AC/DC |
| Kutengwa (V) | 4.000,00 |
| Volti ya kutoa | 5,00 |
| Nguvu ya Kilele (W) | Twenty two |
| Kiunganishi cha kuingiza data | Pin |
| Masafa ya kuingiza | 50 Hz, 60 Hz |
| Muda Mrefu/Usuli | 52.40 |
| Maelezo Marefu | Medical power supply for printed circuit board encapsulated.Source certified for medical applications 2x MOPP (patient protection).Encapsulated format for printed circuit boards.Range of universal input80-264vac.47-63Hz.Voltageoutput5vdc.Intensity ofoutput4A(4.4 A max). Range of output current 0-4A according to demand load.Power:20W(22W for 10s).Efficiency typical:85%.Consumption without load<0,075 W.Protection against short circuit, over load, over voltage and temperature.Requires No minimum load.Level of vibration up to 5G.Input class II without grounding. EMI class B.Low leakage current < 80µA to 264vac.Working temperature: from-35up+85 ° Cof ambient temperature. Consult the technical data sheet to see the curves of drift.Dimensions (Length x Width x Height) [mm]:52,4 x to 27.2 x 24.3 years of warranty.Manufacturer: MEAN WELL.The series MPM are power supply certified for medical use with patient protection, 2 x MOPP (means of patient protection). They have a double protection between input and output 2xMOPP.Have a leakage current (contact current) is very low for a greater security in the application. With low power consumption at no load and requires no minimum load. It has been designed for the most demanding applications at the level of vibration (5G). Sources with class II non-grounded. With an excellent heat dissipation and high useful life thanks to its encapsulation.These sources can be used for medical applications BF (body floating) with the necessary considerations of the system and for industrial applications, and information technology. Suitable for portable medical devices, mobile clinics, monitors and instruments for medical examination. Complies with ANSI/AAMI ES60601-1 and IEC/EN60601-1. |
| Kiunganishi cha kutoa | Pin |
| Aina ya Kiingilio CA | Single-phase |
| Dhamana (Miaka) | 3,00 |
| Nchi ya Asili | China |
Maelezo ya Bidhaa
More details
Vipengele Muhimu
- Ubora wa kiwango cha viwanda
- Inaendana na RoHS
- Imethibitishwa CE
- Dhamana ya mwaka 1
Maelezo ya Kiufundi
Medical power supply for printed circuit board encapsulated.
