MKDSC 5/ 6-7,62 GY BDNZ2202856
MKDSC 5/ 6-7,62 GY BDNZ2202856 1993035 PHOENIX CONTACT PCB terminal block
$0.00USD
3160 kwenye hisa
Vipimo Muhimu
Dokezo:WEEE/RoHS-compliant, free of whiskers according to IEC 60068-2-82/JEDEC JESD 201
Lami:7.62 mm
Upana [w]:45.72 mm
Urefu [h]:26.6 mm
Taarifa za Msambazaji
Bidhaa: 0
Kwa kawaida husafirisha ndani ya siku 2-3 za kazi
Ubora Umeheshimiwa
Usafirishaji wa haraka
Msaada wa Kiufundi
Speci ya Kiufundi
| Kipengele | Thamani |
|---|---|
| Dokezo | WEEE/RoHS-compliant, free of whiskers according to IEC 60068-2-82/JEDEC JESD 201 |
| Lami | 7.62 mm |
| Upana [w] | 45.72 mm |
| Urefu [h] | 26.6 mm |
| Urefu [l] | 12.5 mm |
| Mpangilio wa pini | Linear pinning |
| Mstari wa bidhaa | COMBICON Terminals L |
| Aina ya bidhaa | Printed circuit board terminal |
| Kipenyo cha shimo | 1.3 mm |
| Aina ya kupachika | Press-in technology |
| Idadi ya safu mlalo | 1 |
| Familia ya bidhaa | MKDSC 5 |
| Rangi (Nyumba) | gray (7042) |
| Marekebisho ya makala | 03 |
| Nyenzo ya mawasiliano | Cu alloy |
| Urefu uliowekwa | 21.5 mm |
| Mbinu ya muunganisho | Screw connection with tension sleeve |
| Aina ya kifungashio | packed in cardboard |
| Mchoro wa vipimo | |
| Nyenzo za kuhami joto | PA |
| Idadi ya nafasi | 6 |
| Idadi ya uwezo | 6 |
| Kichwa cha skrubu cha umbo la gari | Slotted (L) |
| Idadi ya miunganisho | 6 |
| Urefu wa pini ya solder [P] | 5.1 mm |
| Sifa za uso | Tin-plated |
| Kikundi cha nyenzo za kuhami joto | I |
| Pini za solder kwa kila uwezo | 1 |
| CTI kulingana na IEC 60112 | 600 |
| Halijoto ya kawaida (mkusanyiko) | -5 °C ... 100 °C |
| Halijoto ya mazingira (uendeshaji) | -40 °C ... 100 °C (Depending on the current carrying capacity/derating curve) |
| Unyevu wa jamaa (uhifadhi/usafiri) | 30 % ... 70 % |
| Ukadiriaji wa kuwaka kulingana na UL 94 | V0 |
| Halijoto ya kawaida (uhifadhi/usafiri) | -40 °C ... 70 °C |
| Eneo la kusugulia uso wa chuma (safu ya juu) | Tin (4 - 8 µm Sn) |
| Sehemu ya mwisho ya uso wa chuma (safu ya juu) | Tin (4 - 8 µm Sn) |
| Kielelezo cha kuwaka kwa waya wa mwanga GWFI kulingana na EN 60695-2-12 | 850 |
| Joto la kuwasha la waya yenye mwanga GWIT kulingana na EN 60695-2-13 | 775 |
| Halijoto kwa ajili ya jaribio la shinikizo la mpira kulingana na EN 60695-10-2 | 125 °C |
Maelezo ya Bidhaa
Terminal block for printed circuit board, nominal cross-section: 4 mm², number of potentials: 6, number of rows: 1, number of poles per row: 6, article family: MKDSC 5, pitch: 7.62 mm, type of connect
Vipengele Muhimu
- Ubora wa kiwango cha viwanda
- Inaendana na RoHS
- Imethibitishwa CE
- Dhamana ya mwaka 1
Nyaraka za Bidhaa
Jalada la data
Speci za kiufundi na data ya utendaji
Mwongozo wa Mtumiaji
Mwongozo wa usakinishaji na uendeshaji
