MKDS 3/ 8-5,08 GY
MKDS 3/ 8-5,08 GY 1128164 PHOENIX CONTACT Terminal for printed circuit board, pitch: 5,08 mm, number of pole..
$0.00USD
4805 kwenye hisa
Vipimo Muhimu
:0.2 mm² / flexible / > 10 N
Kiungo:Screw connection with cage
Hatua:5.08 mm
noti:Complies with WEEE/RoHS, no thread-like materials according to IEC 60068-2-82/JEDEC JESD 201
Taarifa za Msambazaji
Bidhaa: 0
Kwa kawaida husafirisha ndani ya siku 2-3 za kazi
Ubora Umeheshimiwa
Usafirishaji wa haraka
Msaada wa Kiufundi
Speci ya Kiufundi
| Kipengele | Thamani |
|---|---|
| 0.2 mm² / flexible / > 10 N | |
| Kiungo | Screw connection with cage |
| Hatua | 5.08 mm |
| noti | Complies with WEEE/RoHS, no thread-like materials according to IEC 60068-2-82/JEDEC JESD 201 |
| aina | Modular PCB terminal block |
| Matokeo | Test passed |
| Upeo | 0.35 mm (10 Hz ... 60.1 Hz) |
| Masafa | 10 - 150 - 10 Hz |
| Ufungashaji | Packed in carton |
| Upana [w] | 40.64 mm |
| Urefu [h] | 23 mm |
| Urefu [l] | 11.2 mm |
| Mpangilio wa Pin | Linear Pinning |
| Ukubwa wa shank | 0.9 x 0.9 mm |
| Kasi ya Kufagia | 1 octave/min |
| Halijoto | 850 °C |
| Kuongeza kasi | 5g (60.1 Hz ... 150 Hz) |
| Rangi (Kisanduku) | Grey (7042) |
| Dokezo la matumizi | A predefined tightening torque must always be observed for secure connection. Especially in the case of two- and three-pole PCB terminals, the single contact soldering tip may not block them. For this reason, the terminals must be reinforced when connecting (fixed by hand, reinforcement on the housing). |
| Mstari wa Bidhaa | COMBICON Terminals M |
| Aina ya Bidhaa | PCB terminal block |
| Kipenyo cha shimo | 1.3 mm |
| Aina ya kupachika | Wave Soldering |
| Article review | 00 |
| Idadi ya safu mlalo | 1 |
| Familia ya Bidhaa | MKDS 3 |
| Shank Distance | 15.24 mm |
| Kumaliza Uso | Galvanic tin plating |
| Idadi ya nguzo | 8 |
| Maelekezo ya Mtihani | X, Y, and Z axis |
| Nyenzo ya Mawasiliano | Cu Alloy |
| Imekadiriwa Sasa IN | 24 A |
| Volti iliyokadiriwa UN | 400 V |
| Kukaza torque | 0.5 Nm ... 0.6 Nm |
| Vipimo vya Mtihani | DIN EN 60998-2-1 (VDE 0613-2-1):2005-03 |
| Mchoro wa Vipimo | |
| Urefu wa Ufungaji | 18 mm |
| Nyenzo ya insulation | PA |
| Sehemu mtambuka ya nominella | 2.5 mm² |
| Volti ya ukubwa (II/2) | 630 V |
| Urefu wa Shina la Kulehemu [P] | 5 mm |
| Volti ya ukubwa (III/2) | 400 V |
| Volti ya ukubwa (III/3) | 250 V |
| Muda wa jaribio kwa kila ekseli | 2.5 h |
| Muda wa maombi | 5 s |
| Kichwa cha skrubu cha aina ya kifaa | Longitudinal slit (L) |
| Kikundi cha Nyenzo za Insulation | The |
| CTI kulingana na IEC 60112 | 600 |
| AWG ya sehemu mtambuka ya kondakta | 24 ... 12 |
| Volti ya Msukumo Iliyokadiriwa (II/2) | 4 kV |
| Thamani ya chini kabisa ya kuteleza (II/2) | 3.2 mm |
| Volti ya msukumo iliyokadiriwa (III/2) | 4 kV |
| Volti ya msukumo iliyokadiriwa (III/3) | 4 kV |
| Sehemu ngumu ya kondakta | 0.2 mm² ... 4 mm² |
| Ukubwa wa Voltage ya Msukumo (II/2) | 4 kV |
| Halijoto ya kawaida (kuweka) | -5 °C ... 100 °C |
| Thamani ya chini kabisa (III/2) | 3 mm |
| Thamani ya chini kabisa (III/3) | 3.2 mm |
| Dokezo kwenye Sehemu ya Muunganisho | In case of conductor connected by 4 mm² (rigid). |
| Volti ya Kutenga Iliyokadiriwa (II/2) | 630 V |
| Ukubwa wa Voltage ya Msukumo (III/2) | 4 kV |
| Ukubwa wa voltage ya msukumo (III/3) | 4 kV |
| Halijoto ya mazingira (inayofanya kazi) | -40 °C ... 100 °C (Depending on current flow curve/derating curve) |
| Volti ya Kutenga Iliyokadiriwa (III/2) | 400 V |
| Sehemu ya msalaba ya kondakta inayobadilika | 0.2 mm² ... 2.5 mm² |
| Sharti la uthibitisho wa joto | Temperature rise ≤ 45 K |
| Volti ya insulation iliyokadiriwa (III/3) | 250 V |
| Urefu wa sehemu itakayovuliwa | 8 mm |
| Idadi ya Pini za Kulehemu kwa Kila Uwezo | 1 |
| Halijoto ya kawaida (uhifadhi/usafiri) | -40 °C ... 70 °C |
| Darasa la mwako kulingana na UL 94 | V0 |
| Unyevu wa jamaa (usafiri na uhifadhi) | 30 % ... 70 % |
| Eneo la Kuchomea Chuma Uso (Safu ya Uso) | Tin (4 - 8 μm Sn) |
| Viendeshaji 2 vya sehemu msalaba sawa, ngumu | 0.2 mm² ... 1.5 mm² |
| Upinzani wa Insulation Kati ya Nguzo Zilizoungana | 109Ω |
| Uso wa Chuma, Sehemu ya Kuunganisha (Safu ya Uso) | Tin (4 - 8 μm Sn) |
| Viendeshaji 2 vya sehemu inayoweza kunyumbulika inayofanana | 0.2 mm² ... 1.5 mm² |
| Thamani ya chini kabisa ya utambaaji - safu isiyo sawa (II/2) | 3 mm |
| Thamani ya chini kabisa ya kutambaa - safu isiyo sawa (III/2) | 3 mm |
| Thamani ya chini kabisa ya kibali - masafa yasiyo sawa (III/3) | 3 mm |
| Upinzani dhidi ya mikondo ya uso (DIN EN 60112 (VDE 0303-11)) | CTI 600 |
| Joto la mtihani wa ugumu wa Brinell kulingana na EN 60695-10-2 | 125 °C |
| Joto la kuwasha la filamenti ya GWIT kulingana na EN 60695-2-13 | 775 |
| Kielezo cha kuwaka kwa filamenti ya GWFI kulingana na EN 60695-2-12 | 850 |
| Sehemu ya msalaba ya kondakta inayonyumbulika yenye lug iliyowekwa na kola ya plastiki | 0.25 mm² ... 2.5 mm² |
| Sehemu ya msalaba ya kondakta inayonyumbulika yenye kebo bila kola ya plastiki | 0.25 mm² ... 2.5 mm² |
| Sehemu mtambuka ya kondakta/aina ya kondakta/thamani ya kawaida ya nguvu ya mvutano/thamani halisi | 0.2 mm² / rigid / > 10 N |
| Viendeshaji 2 vya sehemu moja inayonyumbulika yenye kipete bila kola ya plastiki | 0.25 mm² ... 0.75 mm² |
| Viendeshaji 2 vya sehemu mtambuka vinavyofanana vinavyonyumbulika vyenye kipete cha TWIN chenye kola ya plastiki | 0.5 mm² ... 1.5 mm² |
Maelezo ya Bidhaa
Terminal block for printed circuit board, nominal current: 24 A, nominal voltage (III/2): 400 V, nominal section: 2.5 mm², number of rows: 1, number of poles per row: 8, article family: MKDS 3, pitch:
