KAA-8R-10
KAA-8R-10 MEANWELL 8-fold Universal Switching Actuator, 10A per channel
$0.00USD
4635 kwenye hisa
Vipimo Muhimu
Jina (Maelezo):KAA-8R-10
Jimbo (Maelezo):New
Hisa (Maelezo):Yes
Muundo (Maelezo):Din Rail
Taarifa za Msambazaji
MEANWELL
Bidhaa: 6448
Kwa kawaida husafirisha ndani ya siku 2-3 za kazi
Ubora Umeheshimiwa
Usafirishaji wa haraka
Msaada wa Kiufundi
Speci ya Kiufundi
| Kipengele | Thamani |
|---|---|
| Jina (Maelezo) | KAA-8R-10 |
| Jimbo (Maelezo) | New |
| Hisa (Maelezo) | Yes |
| Muundo (Maelezo) | Din Rail |
| Mfululizo (Maelezo) | KAA-8R-10 |
| Idhini (Maelezo) | EC |
| Fomu ndogo (Maelezo) | Ladder |
| Upana (mm) (Maelezo) | 72.00 |
| Urefu (mm) (Maelezo) | 90.00 |
| No. Outputs (Details) | Eight |
| Maombi (Maelezo) | Building automation, Lighting, Industrial |
| Mtengenezaji (Maelezo) | MEAN WELL |
| Aina ya bidhaa (Maelezo) | Actuator |
| Kiunganishi cha kuingiza (Maelezo) | Quick Connector |
| Muda Mrefu/Usuli (Maelezo) | 57.00 |
| Maelezo Marefu (Maelezo) | Actuator KNX 8-channel.Functions of scenes and time programmable.Format to install on a Din rail.Self-powered from the bux KNX (21-31V)Consumption of entry to <180mW.8 relay outputsfree of potential10 Amps.Maximum capacitive load per output 220µF.Voltage relay 230vac 50Hz.Maximum currenttotal output56A.Mechanical life operating>10Six.Button for programming individial address.Working temperature: from-30ºCup+45 ° Cof ambient temperature.Dimensions (Width x Height x depth):72 x 90 x 57mm. 4UWidth Din rail.3 years warranty.Manufacturer: MEAN WELL.CLICK VIDEO KAA-8R KNX.The actuators of the series KAA-8R allows the independent control of relays to control lighting, heating, ventilation, blinds, etc.. they Have a compact size with a width of 72mm (4U), suitable for distribution boards, EIB and KNX. The equipment is self-powered from the KNX bus. The relays are especially designed for inductive loads, such as motors and blinds. The device is programmed using the software ETS5.0 and drivers, can be downloaded from the page of KNX http://www.meanwell.com/productCatalog.aspxThe series KAA-8R is ideal for automation and control solutions for smart buildings. |
| Kiunganishi cha kutoa (Maelezo) | Screw-Type |
| Dhamana (Miaka) (Maelezo) | 3,00 |
| Nchi ya Asili (Maelezo) | China |
| Current per channel (A) (Details) | Ten |
| Maximum Current Total (A) (Details) | Fifty six |
Maelezo ya Bidhaa
More details
Vipengele Muhimu
- Ubora wa kiwango cha viwanda
- Inaendana na RoHS
- Imethibitishwa CE
- Dhamana ya mwaka 1
Maelezo ya Kiufundi
Actuator KNX 8-channel.
Nyaraka za Bidhaa
Jalada la data
Speci za kiufundi na data ya utendaji
Mwongozo wa Mtumiaji
Mwongozo wa usakinishaji na uendeshaji
