HVGC-320-1400A
HVGC-320-1400A MEANWELL AC-DC Single Output LED driver Constant Current (CC) with built-in PFC, Output 234VD..
$0.00USD
3888 kwenye hisa
Vipimo Muhimu
Jina:HVGC-320-1400A
Jimbo:Recommended Model
Muundo:Box
Mfululizo:HVGC-320-A
Taarifa za Msambazaji
MEANWELL
Bidhaa: 6448
Kwa kawaida husafirisha ndani ya siku 2-3 za kazi
Ubora Umeheshimiwa
Usafirishaji wa haraka
Msaada wa Kiufundi
Speci ya Kiufundi
| Kipengele | Thamani |
|---|---|
| Jina | HVGC-320-1400A |
| Jimbo | Recommended Model |
| Muundo | Box |
| Mfululizo | HVGC-320-A |
| Idhini | EC, EAC, ENEC, MM, UL |
| Nguvu (W) | 320,00 |
| Fomu ndogo | IP65 |
| Upana (mm) | 90.00 |
| Urefu (mm) | 43.80 |
| Kiwango cha juu cha kuingiza AC | 528,00 |
| Kiwango cha chini cha kuingiza AC | 180,00 |
| Maombi | Lighting |
| Mtengenezaji | MEAN WELL |
| Aina ya bidhaa | LED Driver |
| Kutengwa (V) | 3.750,00 |
| Nguvu ya Kilele (W) | Three hundred twenty |
| Kiunganishi cha kuingiza data | Cable |
| Masafa ya kuingiza | 50 Hz, 60 Hz |
| Muda Mrefu/Usuli | 262.00 |
| Maelezo Marefu | LED driver with phase input.Specially designed for powering LEDs directly in a steady stream.Format in metal boxIP65.Input range180-528Vca47-63Hz.Output in constant current1400mA.Adjustable by external potentiometer (700-1400mA).Range of output voltage with current mode constant114,3-228.6 Vdcaccording to demand load.Power:320W.Efficiency typical:93,5%.Potentiometer:This model incorporates 1 external potentiometer that allows us to regulate the maximum output current.Input class I with grounding.Factor corrector, power>0,98to 230vac at full load.Operating temperature range of caseTcfrom-40ºCup+90ºC.Dimensions (Length x Width x Height):262 x 90 x 43.8 mm5 years of warranty.Manufacturer: MEAN WELLThis source can work directly with leds (plates LED or COBs), not with LED strips. Must be equipment that is fed in a steady stream.This source works on a constant current when we connect the LEDs directly to have a voltage within the range of output voltage mode constant current and a working current equal to the output current. The output current can be adjusted byexternal potentiometerlocated in the housing of the source.The series HVG are LED drivers, class I grounded.With metal housing IP65. The series HVG has a high efficiency designed for applications of public lighting, exterior, interior, or any application of LED lighting. Approved HL Class I Division 2 for ex-zones in the US. Complies with the requirements of security at the global level for lighting.If you want to regulate the LED strips we recommend the series PWM. |
| Kiunganishi cha kutoa | Cable |
| Aina ya Kiingilio CA | Three-phase |
| Dhamana (Miaka) | 5,00 |
| Nchi ya Asili | China |
| Mkondo wa kutoa mA | 700, 750, 800, 850, 900, 950, 1000, 1050, 1100, 1150, 1200, 1250, 1300, 1350, 1400 |
| Kiwango cha Chini cha Pato (mA) | 700,00 |
| Kiwango cha Upeo wa Pato (mA) | 1.400,00 |
Maelezo ya Bidhaa
More details
Vipengele Muhimu
- Ubora wa kiwango cha viwanda
- Inaendana na RoHS
- Imethibitishwa CE
- Dhamana ya mwaka 1
Maelezo ya Kiufundi
LED driver with phase input.
Nyaraka za Bidhaa
Jalada la data
Speci za kiufundi na data ya utendaji
Mwongozo wa Mtumiaji
Mwongozo wa usakinishaji na uendeshaji
