HLG-480H-42AB
HLG-480H-42AB MEANWELL AC-DC Single output LED driver Mix mode (CV+CC) with built-in PFC, Output 42VDC / 11...
$0.00USD
4718 kwenye hisa
Vipimo Muhimu
Jina:HLG-480H-42AB
Jimbo:New
Muundo:Box
Mfululizo:HLG-480H-V-AB
Taarifa za Msambazaji
MEANWELL
Bidhaa: 6448
Kwa kawaida husafirisha ndani ya siku 2-3 za kazi
Ubora Umeheshimiwa
Usafirishaji wa haraka
Msaada wa Kiufundi
Speci ya Kiufundi
| Kipengele | Thamani |
|---|---|
| Jina | HLG-480H-42AB |
| Jimbo | New |
| Muundo | Box |
| Mfululizo | HLG-480H-V-AB |
| Kufifia | 0-10V, 1-10V, Resistance 0-100K, PWM Signal 10V |
| Idhini | CCC, CE, EAC, ENEC, RCM, UL |
| Nguvu (W) | 478,80 |
| Fomu ndogo | IP65 |
| Upana (mm) | 125.00 |
| Urefu (mm) | 43.80 |
| Kiwango cha juu cha kuingiza AC | 305,00 |
| Kiwango cha chini cha kuingiza AC | 90,00 |
| Maombi | Lighting |
| Mtengenezaji | MEAN WELL |
| Aina ya bidhaa | LED Driver |
| Kutengwa (V) | 3.750,00 |
| Nguvu ya Kilele (W) | 478.8 |
| Kiunganishi cha kuingiza data | Cable |
| Masafa ya kuingiza | 50 Hz, 60 Hz |
| Muda Mrefu/Usuli | 262.00 |
| Maelezo Marefu | LED driver dimmable.Specially designed for powering LEDs directly in a steady stream.Format in metal boxIP65.Input range90-305Vca47-63Hz.Output in constant currentAn 11.4-A.Adjustable by external potentiometer (5,7-11.4 To).Range of output voltage with current mode constant21 to 42Vccaccording to demand load.The output voltage in voltage mode constant42Vcc. Adjustable by external potentiometer (35,7-44,1 Vcc).Power:478,8 W.Efficiency typical:95%.Potentiometers:This model incorporates 2 external potentiometers that allows us to regulate the output voltage and the maximum output current.Regulation0% to 100% of the output intensity with a slider0-10V / 1-10V,a PWM signal of 10V with a frequency of 100Hz to 3KHz or resistance of 0 to 100K Ohms. With the regulation we can turn off the output, but we need a regulator 0-10V. Regulators 1-10V not arrive to give 0V do not shut down the output.Input class I with grounding.Factor corrector, power>0,97to 230vac at full load.Operating temperature range of caseTcfrom-40ºCup+90ºC.Dimensions (Length x Width x Height):262 x 125 x 43.8 mm7 years of warranty.Manufacturer: MEAN WELLThis source is designed to work directly with leds (plates LED or COBs), not with LED strips. Must be equipment that is fed in a steady stream.This source works on a constant current when we connect the LEDs directly to have a voltage within the range of output voltage mode constant current and a working current equal to the output current.In this version AB, the output current and the output voltage can be adjusted byexternal potentiometerslocated in the housing of the source,in addition to having regulation 0-10V/1-10V, 10V PWM, or resistance.The series HLG are LED drivers, class I grounded.You can also work in voltage mode constant giving a fixed voltage of 42V if the load is powered at constant voltage and does not overcome the maximum output power.With metal housing IP65. The series HLG has a high efficiency designed for applications of public lighting, architectural, exterior, interior or any lighting application LED needs a driver of high quality. Approved HL Class I Division 2 for ex-zones in the US. Suitable for LED lighting or LED displays. Complies with the requirements of security at the global level for lighting.Can be adjusted by regulatory assets or liabilities0-10Vor1-10V, signal 10V PWM of 100Hz to 3KHz or by resistance of 0 to 100KOhmios. Does not work with dimmers Triac dimmer cutting phase.(Not to be confused with regulators TRIACs, cutting phase. This driver cannot be regular with a Triac).With potentiometers assets that you can give 0V to shut down the output without the need of a switch. Dimmers 1-10V we can only reach 10% of regulation without shutting down the output. If you want to regulate the LED strips we recommend the series PWM.Compatible with any regulator 0-10V or 1-10V-market both assets and liabilities. Some compatible models tested are:MEAN WELL DAP-04S01 (compatible with any push button normally open).SIMON: 75317BJC: 5TC8 425LEGRAND: 0784 04ABB- "NIESSEN": N2260.9SIEMENS: 5TC8424EFAPEL: Model 21210LED BOX: Model LD1160188OSRAM: Model DIM MCUJUNG: Model 240-10We can put about 20 sources for each regulator. The maximum distance is 100 meters between the regulator and the driver. |
| Kiunganishi cha kutoa | Cable |
| Aina ya Kiingilio CA | Single-phase |
| Dhamana (Miaka) | 7,00 |
| Nchi ya Asili | Taiwan |
| Mkondo wa kutoa mA | 5500, 6000, 7000, 8000, 9000, 10000, 11000, 12000 |
| Kiwango cha Chini cha Pato (mA) | 5.700,00 |
| Kiwango cha Upeo wa Pato (mA) | 11.400,00 |
Maelezo ya Bidhaa
More details
Vipengele Muhimu
- Ubora wa kiwango cha viwanda
- Inaendana na RoHS
- Imethibitishwa CE
- Dhamana ya mwaka 1
Maelezo ya Kiufundi
LED driver dimmable.
