GSM220A20-R7B
GSM220A20-R7B MEANWELL AC-DC Medical desktop adaptor with Active PFC, Input 3 pin IEC320-C14 socket, Output ..
$0.00USD
3113 kwenye hisa
Vipimo Muhimu
Jina (Maelezo):GSM220A20-R7B
Muundo (Maelezo):Desktop
Mfululizo (Maelezo):GSM220A
Idhini (Maelezo):CE, UL
Taarifa za Msambazaji
MEANWELL
Bidhaa: 6448
Kwa kawaida husafirisha ndani ya siku 2-3 za kazi
Ubora Umeheshimiwa
Usafirishaji wa haraka
Msaada wa Kiufundi
Speci ya Kiufundi
| Kipengele | Thamani |
|---|---|
| Jina (Maelezo) | GSM220A20-R7B |
| Muundo (Maelezo) | Desktop |
| Mfululizo (Maelezo) | GSM220A |
| Idhini (Maelezo) | CE, UL |
| Nguvu (W) (Maelezo) | 220,00 |
| Fomu ndogo (Maelezo) | Encapsulated |
| Upana (mm) (Maelezo) | Eighty five |
| Urefu (mm) (Maelezo) | Forty six |
| Kiwango cha Juu cha Ingizo la AC (Maelezo) | 264,00 |
| Kiwango cha chini cha kuingiza AC (Maelezo) | 80,00 |
| Maombi (Maelezo) | Industrial, Medical, Telecommunications |
| Mtengenezaji (Maelezo) | MEAN WELL |
| Aina ya bidhaa (Maelezo) | Power supply AC/DC |
| Kutengwa (V) (Maelezo) | 4.000,00 |
| Volti ya kutoa (Maelezo) | 20,00 |
| Nguvu ya Kilele (W) (Maelezo) | Two hundred twenty |
| Kiunganishi cha kuingiza (Maelezo) | IEC 320-C14 |
| Masafa ya kuingiza (Maelezo) | 50 Hz, 60 Hz |
| Muda Mrefu/Usuli (Maelezo) | Two hundred ten |
| Maelezo Marefu (Maelezo) | Source switched type desktop adapter with PFC function.Fuentrecertified for medical applications2x MOPP (patient protection).Feeder for connection to a wall outlet.Range of universal input80-264vac47-63Hz.Output voltage20vdc.Output intensity11A. Range of output current 0-11A according to demand load.Power:220W.Efficiency typical:92%.Factor corrector, power>0,91to 230vac at full load.LED Indicator of correct operation.Class l non-grounded.Consumption without load<0,15 W.Working temperature: from-30up+70 ° Cof ambient temperature. Consult the technical data sheet to see the curves of drift.Dimensions (Length x Width x Height) [mm]:210 x 85 x 46.3 years of warranty.Manufacturer: MEAN WELL.Series, GSM-A, are the sources switched in format desktop with input connector europeanIEC320-C14and output connector R7B DIN 4p(Level Vl).The series GSM220 have a low consumption, no-load of only 0.15 W and meet the latest requirements of energy efficiency. |
| Kiunganishi cha kutoa (Maelezo) | R7B DIN 4p |
| Aina ya Kiingilio CA (Maelezo) | Single-phase |
| Dhamana (Miaka) (Maelezo) | 3,00 |
| Nchi ya Asili (Maelezo) | China |
Maelezo ya Bidhaa
More details
Vipengele Muhimu
- Ubora wa kiwango cha viwanda
- Inaendana na RoHS
- Imethibitishwa CE
- Dhamana ya mwaka 1
Maelezo ya Kiufundi
Source switched type desktop adapter with PFC function.
Nyaraka za Bidhaa
Jalada la data
Speci za kiufundi na data ya utendaji
Mwongozo wa Mtumiaji
Mwongozo wa usakinishaji na uendeshaji
