FED40-12S24
FED40-12S24 MEANWELL DC-DC converter for PCB mount, Input: 9-18VDC. Output: 24VDC. 20mA. Power: 40W. I/O iso..
$0.00USD
4978 kwenye hisa
Vipimo Muhimu
Jina:FED40-12S24
Muundo:For Printed Circuit
Mfululizo:FED40
Idhini:CE, UL
Taarifa za Msambazaji
MEANWELL
Bidhaa: 6448
Kwa kawaida husafirisha ndani ya siku 2-3 za kazi
Ubora Umeheshimiwa
Usafirishaji wa haraka
Msaada wa Kiufundi
Speci ya Kiufundi
| Kipengele | Thamani |
|---|---|
| Jina | FED40-12S24 |
| Muundo | For Printed Circuit |
| Mfululizo | FED40 |
| Idhini | CE, UL |
| Nguvu (W) | 40,00 |
| Fomu ndogo | DIP |
| Upana (mm) | 25.4 |
| Urefu (mm) | 10.2 |
| Kipindi cha kuingiza data | 2:1 |
| Maombi | Building automation, Industrial, Telecommunications |
| Kiwango cha juu cha kuingiza cha DC | 18,00 |
| Kiwango cha chini cha kuingiza cha DC | 9,00 |
| Mtengenezaji | P-DUKE |
| Aina ya bidhaa | Dc/DC converters |
| Kutengwa (V) | 1.600,00 |
| Volti ya kutoa | 24,00 |
| Nguvu ya Kilele (W) | Forty |
| Ingizo la DC la Masafa | 9, 9,2, 9,9, 10, 10,5, 10,8, 12, 13,2, 13,5, 14, 14,4, 15, 16,2, 16,5, 16,8, 18 |
| Kiunganishi cha kuingiza data | Pin |
| Muda Mrefu/Usuli | 50.8 |
| Maelezo Marefu | Dc/DC converter to the printed circuit board in format DIP, with isolation of 1600Vcc, regulated.Plastic box.FormatDIPfor soldering on printed circuit boards.Input range9-18vdc.Output voltage24vdc.Output intensity20mA.Power:40W.Isolation input-output 1600Vcc.Efficiency typical: 91%.Low noise and ripple 150mVp-p.Minimum load of 10%. The no-load operation will not damage the converter but will not meet all specifications.Working temperature: from-40up+105ºC. See the curve of drift according to the temperature in the technical data sheet.Dimensions (Length x Width x Height) [mm]:50.8 x 25.4 x 10.2.3 years of warranty.Manufacturer: P-DUKE.The converters of the series FED40 have a wide input range 2:1 and an isolation between input and output of 1600Vcc. Are protected against overloads and short-circuits.CE certificates and US. |
| Kiunganishi cha kutoa | Pin |
| Dhamana (Miaka) | 3,00 |
| Nchi ya Asili | Taiwan |
Maelezo ya Bidhaa
More details
Vipengele Muhimu
- Ubora wa kiwango cha viwanda
- Inaendana na RoHS
- Imethibitishwa CE
- Dhamana ya mwaka 1
Maelezo ya Kiufundi
Dc/DC converter to the printed circuit board in format DIP, with isolation of 1600Vcc, regulated.
