ELG-75-24-3Y
ELG-75-24-3Y MEANWELL AC-DC Single output LED Driver (CC+CV) with PFC, 3 wire input, Output 24VDC / 3.15A, C..
$0.00USD
4863 kwenye hisa
Vipimo Muhimu
Jina (Maelezo):ELG-75-24-3Y
Jimbo (Maelezo):Recommended Model
Hisa (Maelezo):Yes
Muundo (Maelezo):Box
Taarifa za Msambazaji
MEANWELL
Bidhaa: 6448
Kwa kawaida husafirisha ndani ya siku 2-3 za kazi
Ubora Umeheshimiwa
Usafirishaji wa haraka
Msaada wa Kiufundi
Speci ya Kiufundi
| Kipengele | Thamani |
|---|---|
| Jina (Maelezo) | ELG-75-24-3Y |
| Jimbo (Maelezo) | Recommended Model |
| Hisa (Maelezo) | Yes |
| Muundo (Maelezo) | Box |
| Mfululizo (Maelezo) | ELG-75-V |
| Idhini (Maelezo) | CCC, CE, EAC, ENEC, KCC, MM, RCM, UL |
| Nguvu (W) (Maelezo) | 75,60 |
| Fomu ndogo (Maelezo) | IP67 |
| Upana (mm) (Maelezo) | 63.00 |
| Urefu (mm) (Maelezo) | 35.50 |
| Kiwango cha Juu cha Ingizo la AC (Maelezo) | 305,00 |
| Kiwango cha chini cha kuingiza AC (Maelezo) | 100,00 |
| Maombi (Maelezo) | Lighting |
| Mtengenezaji (Maelezo) | MEAN WELL |
| Aina ya bidhaa (Maelezo) | LED Driver |
| Kutengwa (V) (Maelezo) | 3.750,00 |
| Volti ya kutoa (Maelezo) | 24,00 |
| Nguvu ya Kilele (W) (Maelezo) | 75.6 |
| Kiunganishi cha kuingiza (Maelezo) | Quick Connector |
| Masafa ya kuingiza (Maelezo) | 50 Hz, 60 Hz |
| Muda Mrefu/Usuli (Maelezo) | 180.00 |
| Maelezo Marefu (Maelezo) | LED Driver.Specially designed to feed LED strips.Format in metal box SealedIP67.Input range100-305Vca47-63Hz.Output voltage24vdc.Output intensity3.15 A.Range of output current 0-3,15 according To the demand load.Power:75,6 W.Efficiency typical:88%.Input class I with grounding. Input with 3 wires for ground.Factor corrector, power>0.95to 230vac at full load.Consumption without load <0.5 W.Operating temperature range of caseTcfrom-40ºCup+85 ° CDimensions (Length x Width x Height):180 x 63 x 35.5 mm5 years of warranty.Manufacturer: MEAN WELL.This source is designed to work directly with LED strips or LED bulbs, which are fed at constant voltage. Working mode constant voltage giving a fixed voltage of 24V if the load is powered at constant voltage and does not overcome the maximum output power.The series ELG are Led drivers, class I grounded. The own metal box serves to connect the ground of security. You can ask for a version with ground cable from the input (3 wires) by adding-3Y at the end of the model. For example ELG-75-24-3Y.This source can operate in either constant current when we connect the LEDs directly to have a voltage within the range of output voltage mode constant current and a working current equal to the output current.With metal housing, waterproof to IP67. The series ELG has a high efficiency designed for applications of public lighting, architectural, outdoor or any application of LED lighting need a driver of high quality. Approved HL Class I Division 2 for ex-zones in the US. |
| Kiunganishi cha kutoa (Maelezo) | Cable |
| Aina ya Kiingilio CA (Maelezo) | Single-phase |
| Dhamana (Miaka) (Maelezo) | 5,00 |
| Nchi ya Asili (Maelezo) | China |
Maelezo ya Bidhaa
More details
Vipengele Muhimu
- Ubora wa kiwango cha viwanda
- Inaendana na RoHS
- Imethibitishwa CE
- Dhamana ya mwaka 1
Maelezo ya Kiufundi
LED Driver.
Nyaraka za Bidhaa
Jalada la data
Speci za kiufundi na data ya utendaji
Mwongozo wa Mtumiaji
Mwongozo wa usakinishaji na uendeshaji
