ELG-240-C1400
ELG-240-C1400 MEANWELL AC-DC Single output LED driver Constant current (CC) with built-in PFC, Output 171VDC..
$0.00USD
4423 kwenye hisa
Vipimo Muhimu
Jina:ELG-240-C1400
Jimbo:Do not Use for New Designs
Muundo:Box
Mfululizo:ELG-240-C
Taarifa za Msambazaji
MEANWELL
Bidhaa: 6448
Kwa kawaida husafirisha ndani ya siku 2-3 za kazi
Ubora Umeheshimiwa
Usafirishaji wa haraka
Msaada wa Kiufundi
Speci ya Kiufundi
| Kipengele | Thamani |
|---|---|
| Jina | ELG-240-C1400 |
| Jimbo | Do not Use for New Designs |
| Muundo | Box |
| Mfululizo | ELG-240-C |
| Idhini | CCC, CE, EAC, ENEC, KCC, MM, RCM, UL |
| Nguvu (W) | 239,40 |
| Fomu ndogo | IP67 |
| Upana (mm) | 71.00 |
| Urefu (mm) | 37.50 |
| Kiwango cha juu cha kuingiza AC | 305,00 |
| Kiwango cha chini cha kuingiza AC | 100,00 |
| Maombi | Lighting |
| Mtengenezaji | MEAN WELL |
| Aina ya bidhaa | LED Driver |
| Kutengwa (V) | 3.750,00 |
| Nguvu ya Kilele (W) | 239.4 |
| Kiunganishi cha kuingiza data | Cable |
| Masafa ya kuingiza | 50 Hz, 60 Hz |
| Muda Mrefu/Usuli | 244.00 |
| Maelezo Marefu | LED driver.Specially designed for powering LEDs directly in a steady stream.Format in metal box sealedIP67.Input range100-305Vca47-63Hz.Output in constant current1400mA.Range of output voltage with current mode constant86 to 171Vccaccording to demand load.Power:239,4 W.Efficiency typical:93%.Input class I with grounding.Factor corrector, power>0.95to 230vac at full load.Consumption without load <0.5 W.Operating temperature range of caseTcfrom-40ºCup+85ºC.Dimensions (Length x Width x Height):244 x 71 x 37.5 mm5 years of warranty.Manufacturer: MEAN WELL.This source is designed to work directly with leds (plates LED or COBs), not with LED strips. Must be equipment that is fed in a steady stream.This source works on a constant current when we connect the LEDs directly to have a voltage within the range of output voltage mode constant current and a working current equal to the output current.The series ELG are LED drivers, class I grounded. The own metal box serves to connect the ground of security. You can ask for a version with ground cable from the input (3 wires) by adding-3Y at the end of the model. For example ELG-240-C1400-3Y.With metal housing, waterproof to IP67. The series ELG has a high efficiency designed for applications of public lighting, architectural, outdoor or any application of LED lighting need a driver of high quality. Approved HL Class I Division 2 for ex-zones in the US. |
| Kiunganishi cha kutoa | Cable |
| Aina ya Kiingilio CA | Single-phase |
| Dhamana (Miaka) | 5,00 |
| Nchi ya Asili | China |
| Mkondo wa kutoa mA | One thousand four hundred |
| Kiwango cha Chini cha Pato (mA) | 1.400,00 |
| Kiwango cha Upeo wa Pato (mA) | 1.400,00 |
Maelezo ya Bidhaa
More details
Vipengele Muhimu
- Ubora wa kiwango cha viwanda
- Inaendana na RoHS
- Imethibitishwa CE
- Dhamana ya mwaka 1
Maelezo ya Kiufundi
LED driver.
