DRP-3200-48CAN
DRP-3200-48CAN MEANWELL AC-DC Single output Rack front end power supply, Output 48VDC / 67A, 1U low profile,..
$0.00USD
3076 kwenye hisa
Vipimo Muhimu
Fan (Details):Yes
Jina (Maelezo):DRP-3200-48CAN
Jimbo (Maelezo):New
Alarms (Details):Over Temperature, Input Fault, Output OK, Overload
Taarifa za Msambazaji
MEANWELL
Bidhaa: 6448
Kwa kawaida husafirisha ndani ya siku 2-3 za kazi
Ubora Umeheshimiwa
Usafirishaji wa haraka
Msaada wa Kiufundi
Speci ya Kiufundi
| Kipengele | Thamani |
|---|---|
| Fan (Details) | Yes |
| Jina (Maelezo) | DRP-3200-48CAN |
| Jimbo (Maelezo) | New |
| Alarms (Details) | Over Temperature, Input Fault, Output OK, Overload |
| Muundo (Maelezo) | 19"Rack |
| Mfululizo (Maelezo) | DRP-3200 |
| Idhini (Maelezo) | EC, EAC, UL |
| Interface (Details) | CANBus, I2C |
| Nguvu (W) (Maelezo) | 3.216,00 |
| Fomu ndogo (Maelezo) | 1U |
| Upana (mm) (Maelezo) | 107.00 |
| Urefu (mm) (Maelezo) | 41.00 |
| Kiwango cha Juu cha Ingizo la AC (Maelezo) | 264,00 |
| Kiwango cha chini cha kuingiza AC (Maelezo) | 90,00 |
| Maombi (Maelezo) | Industrial |
| Mtengenezaji (Maelezo) | MEAN WELL |
| Aina ya bidhaa (Maelezo) | Power supply AC/DC |
| Kutengwa (V) (Maelezo) | 3.000,00 |
| Volti ya kutoa (Maelezo) | 48,00 |
| Nguvu ya Kilele (W) (Maelezo) | Three thousand two hundred sixteen |
| Kiunganishi cha kuingiza (Maelezo) | Pin |
| Masafa ya kuingiza (Maelezo) | 50 Hz, 60 Hz |
| Muda Mrefu/Usuli (Maelezo) | 325.00 |
| Maelezo Marefu (Maelezo) | Power supply for 19" Rack programmable viaITwoCand CANBus.FormatRack 19".Range of universal input90-264vac.47-63Hz.Output voltage48vdc.Adjustable by potentiometer (47,5-58,8 Vcc) using external signal 0,4-4,7 Vdc from 50% to 125%or configurable by protocol ITwoC orCANBus.Output intensity67A. Range of output current 0-67A according to demand load. Adjustable by external signal from 20% up to 100%or configurable by protocol ITwoC orCANBus.Power:3216W.Efficiency typical:94.5 per cent.Paralelizable up to 4 units with sharing of active current and diode mosfet protection integrated in the source.Hot Swap. Change in hot.Factor corrector, power>0,97to 230vac at full load.Protocol ITwoC and CANBus.Remote on / off.Auxiliary outputs of 5V AT 0.3 A and-12V at 0.8 A.2-colour LED charging status indicator.Protection against short circuit, over load, over voltage and temperature.Working temperature: from-30up+70 ° Cof ambient temperature. Consult the technical data sheet to see the curves of drift.Dimensions (Length x Width x Height) [mm]:325 x 107 x 41.5 years of warranty.Manufacturer: MEAN WELL.The power supplies of the series DRP-3200-48CAN are designed to install in the Rack DHP-1UT that supports up to 4 sources DRP-3200.These sources allow you to configure both the output current as the output voltage through the CANBus.Can be connected in parallel up to 4 sources protected by a diode Mosfet for the protection of the current investment. They have a wide range of temperature from -30ºC up to +70ºC. Have a high efficiency and auxiliary outputs of 5V and 12V. The function Hot-Swap or hot-swap allows us to replace any damaged equipment without having to stop the system, or to increase the power at any time. Protection against short circuit, over load, over voltage and temperature.The series DRP-3200 is certified, CE, UL, EAC, UL/en/IEC 62368-1, IN 55032/55024. |
| Kiunganishi cha kutoa (Maelezo) | Screw-Type |
| Aina ya Kiingilio CA (Maelezo) | Single-phase |
| Dhamana (Miaka) (Maelezo) | 5,00 |
| Nchi ya Asili (Maelezo) | Taiwan |
Maelezo ya Bidhaa
More details
Vipengele Muhimu
- Ubora wa kiwango cha viwanda
- Inaendana na RoHS
- Imethibitishwa CE
- Dhamana ya mwaka 1
Maelezo ya Kiufundi
Power supply for 19" Rack programmable viaITwoCand CANBus.
