Kipatikana Bidhaa Maarufu
DRC-100B
DRC-100B MEANWELL AC-DC DIN rail single output power supply with battery charger (UPS function), Output 27.6..
$0.00USD
4109 kwenye hisa
Vipimo Muhimu
Loo:7, 8, 9, 10, 12, 15, 20
Jina:DRC-100B
Hisa:Yes
Kengele:Low battery, Input OK
Taarifa za Msambazaji
MEANWELL
Bidhaa: 6448
Kwa kawaida husafirisha ndani ya siku 2-3 za kazi
Ubora Umeheshimiwa
Usafirishaji wa haraka
Msaada wa Kiufundi
Speci ya Kiufundi
| Kipengele | Thamani |
|---|---|
| Loo | 7, 8, 9, 10, 12, 15, 20 |
| Jina | DRC-100B |
| Hisa | Yes |
| Kengele | Low battery, Input OK |
| Muundo | Din Rail |
| Mfululizo | DRC-100 |
| Matokeo 1 | +24 |
| Idhini | CE, UL |
| Nguvu (W) | 96,60 |
| Fomu ndogo | Narrow |
| Upana (mm) | 55.00 |
| Urefu (mm) | 90.00 |
| Maombi | Building automation, Industrial, Telecommunications |
| Aina ya betri | Lead, AGM, Wet |
| Mtengenezaji | MEAN WELL |
| Aina ya bidhaa | UPS |
| Hatua za kuchaji | Two |
| Kutengwa (V) | 3.000,00 |
| Nguvu ya Kilele (W) | 96.6 |
| Kiunganishi cha kuingiza data | Screw-Type |
| Muda Mrefu/Usuli | 100.00 |
| Maelezo Marefu | UPS input switches and output continuously.Format to install on a Din rail.Range of universal input90-264vac. 47-63Hz.Output voltagefor the loadwith power: 27,6 Vdc.Output voltage in battery mode: voltage of the battery.Output intensity2.25 To. Peak 3.5 A.Float voltageadjustable24-30vdc. (The setting of the float voltage also adjusts the output voltage of power supply).Intensity of load1.25 To.Power:96,6 W.Type of batteries:Gel, AGM and wet.Battery capacity:7-20Ah.Efficiency typical:89%at full load with power.Protection against deep discharge of the batteries.No cut in output in the step feed mode to battery mode. 0ms transfer time.Alarms correct power AC-OK and low-battery via relay.LED to indicate proper output DC-OK.Working temperature: from-30up+70 ° Cof ambient temperature. Consult the technical data sheet to see the curves of drift.Dimensions (Width x Height x depth) [mm]:55 x 90 x 100.3 years of warranty.Manufacturer: MEAN WELL.The series DRC-100 are the Ups input switches and output continuously. When there is mains power the computer gives a stable output while charging the battery. In case of failure of power supply maintains the output fed from the battery. These power supplies are suitable for security applications, access control and any application that must continue to function even with a power outage.These are protected against overloads, short-circuit in the output, sobrentesión output, low battery and reverse battery polarity (by fuse). They also have alarms through relay which alert us in case of network failure or when the output voltage is lower than a certain value, indicating that the capacity of the battery is low. |
| Kiunganishi cha kutoa | Screw-Type |
| Aina ya Kiingilio CA | Single-phase |
| Dhamana (Miaka) | 3,00 |
| Nchi ya Asili | China |
Maelezo ya Bidhaa
More details
Vipengele Muhimu
- Ubora wa kiwango cha viwanda
- Inaendana na RoHS
- Imethibitishwa CE
- Dhamana ya mwaka 1
Maelezo ya Kiufundi
UPS input switches and output continuously.
Nyaraka za Bidhaa
Jalada la data
Speci za kiufundi na data ya utendaji
Mwongozo wa Mtumiaji
Mwongozo wa usakinishaji na uendeshaji
