CS1W-ID231

CS-Series digitalI/O unitsRack PLCUp to 96 I/O points per unit – input, output or mixedDigital I/O units serve as the PLC's interface to achieve fast, reliable sequence control. A full range of units, from high-speedDC inputs to relay outputs, let you adapt CS1 to your needs.CS1 units are available with various I/O densities and connection technologies. Up to16 I/O points can be wired to units with detachable M3 screw terminalsdirectly. High- density 32- and 64- point I/O units are equippedwith standard40-pin connectors.Prefabricated cables and wiring terminals are available for easy interfacing to high- density I/O units.Ordering informationPointsType Rated voltage Rated currentRemarks Connection typeOrder code*116AC or DC input 120VAC or VDC10 mA – M3 CS1W-IA11116AC input 240 VAC 10 mA – M3 CS1W-IA21116DC input24 VDC7 mA– M3 CS1W-ID21116DC input24 VDC7 mAInputs start interrupt tasks in PLC programM3 CS1W-INT0116DC input24 VDC7 mALatches pulses down to 50 μs pulse width M3 CS1W-IDP0132DC input24 VDC6 mA– 1 × 40 pt Fujitsu CS1W-ID23164DC input24 VDC6 mA– 2 × 40 pt Fujitsu CS1W-ID26196DC input24 VDC5 mA– 2 × 56 pt Fujitsu CS1W-ID2918Triac output250 VAC1.2 A – M3 CS1W-OA20116Triac output250 VAC0.5 A – M3 CS1W-OA2118Relay output 250 VAC2.0 A – M3 CS1W-OC20116Relay output 250 VAC2.0 A – M3 CS1W-OC21116DC output (sink)12 to 24 VDC0.5 A – M3 CS1W-OD21116DC output (source) 24 VDC 0.5 AWith short-circuit protection,alarm M3 CS1W-OD21232DC output (sink) 12 to 24 VDC0.5 A – 1 × 40 pt Fujitsu CS1W-OD23132DC output (source) 24 VDC 0.5 AWith short-circuit protection,alarm 1 × 40 pt Fujitsu CS1W-OD23264DC output (sink) 12 to 24 VDC0.3 A – 2 × 40 pt Fujitsu CS1W-OD26164DC output (source) 24 VDC 0.3 AWith short-circuit protection,alarm 2 × 40 pt Fujitsu CS1W-OD26296DC output (sink) 12 to 24 VDC0.1 A – 2 × 56 pt Fujitsu CS1W-OD29196DC output (source)24 VDC 0.1 A – 2 × 56 pt Fujitsu CS1W-OD29232+32DC output (sink) 12 to 24 VDC0.3 A – 2 × 40 pt Fujitsu CS1W-MD26132+32DC in+out (source) 24 VDC 0.3 AWith short-circuit protection,alarm 2 × 40 pt Fujitsu CS1W-MD26248+48DC output (sink) 12 to 24 VDC0.1 A – 2 × 56 pt Fujitsu CS1W-MD29148+48DC in+out (source) 12 to 24 VDC0.1 A – 2 × 56 pt Fujitsu CS1W-MD292*1C200H I/O units can also be mounted, except on CS1D systems.Note:All Digital I/O units are designated as Basic I/O units.AccessoriesDescription Connection typeOrder codeConnection cable between I/O terminal block and I/O unit with 40-pt Fujitsu connector( _ _ _ = length in cm)Fujitsu (40pt) XW2Z- BI/O terminal block for input unit with 40-pt Fujitsu connectorPush-inXW2R-P34G-C1I/O terminal block for output unit with 40-pt Fujitsu connectorPush-inXW2R-P34G-C3I/O terminal block for input unit with 40-pt Fujitsu connectorClamp XW2R-E34G-C1I/O terminal block for output unit with 40-pt Fujitsu connectorClamp XW2R-E34G-C3I/O terminal block for input unit with 40-pt Fujitsu connectorM3 Screws XW2R-J34G-C1I/O terminal block for output unit with 40-pt Fujitsu connectorM3 Screws XW2R-J34G-C3Note:For I/O Cables and Terminal Blocks, see page 7239
