1SBL176060R2301
1SBL176060R2301 ABB AF16ZB-30-01RTCONT.TRACB.100-250VAC-DC
$0.00USD
4283 kwenye hisa
Vipimo Muhimu
:Main Circuit 690 V
ETIM 4:EC000066 - Magnet contactor, AC-switching
ETIM 5:EC000066 - Magnet contactor, AC-switching
ETIM 6:EC000066 - Power contactor, AC switching
Taarifa za Msambazaji
ABB
Bidhaa: 44170
Kwa kawaida husafirisha ndani ya siku 2-3 za kazi
Ubora Umeheshimiwa
Usafirishaji wa haraka
Msaada wa Kiufundi
Speci ya Kiufundi
| Kipengele | Thamani |
|---|---|
| Main Circuit 690 V | |
| ETIM 4 | EC000066 - Magnet contactor, AC-switching |
| ETIM 5 | EC000066 - Magnet contactor, AC-switching |
| ETIM 6 | EC000066 - Power contactor, AC switching |
| ETIM 7 | EC000066 - Power contactor, AC switching |
| ETIM 8 | EC000066 - Power contactor, AC switching |
| UNSPSC | 39121529 |
| Darasa la mtandaoni | V11.0 : 27371003 |
| Viwango | IEC/EN 60947-1, IEC/EN 60947-4-1, UL 60947-4-1, CSA C22.2 No. 60947-4-1, IEC 60077-1 (applicable parts), IEC 60077-2 (applicable parts), EN 50155 (applicable parts), TR CU 001/2011, IEC 61373, For compliance confirmation on applicable parts based on your application and combination, please consult your ABB sales representatives. |
| Hali ya RoHS | Following EU Directive 2011/65/EU |
| Muda wa Uendeshaji | Between Coil De-energization and NC Contact Closing 13 ... 98 ms |
| Aina ya Kituo | Ring-Tongue Terminals |
| Jamii ya WEEE | 5. Small Equipment (No External Dimension More Than 50 cm) |
| Cheti cha CB | CB_SE-113345 |
| Cheti cha UR | UL_20121122-E312527_9_5 |
| WEEE B2C / B2B | Business To Business |
| Cheti cha CCC | CCC_2010010304445624 |
| Cheti cha CQC | CQC2010010304445624 |
| Cheti cha Jumuiya ya Afrika Mashariki | EAC_RU C-FR ME77 B03597 |
| Kadi ya Orodha ya UL | UL_E312527 |
| Taarifa za RoHS | 2CMT2021-006277 |
| Upana Halisi wa Bidhaa | 45 mm |
| Tamko la REACH | 2CMT2021-006202 |
| Kuhimili Hali ya Hewa | Category B according to IEC 60947-1 Annex Q |
| Urefu Halisi wa Bidhaa | 86 mm |
| Uzito Halisi wa Bidhaa | 0.32 kg |
| Kifurushi cha Kiwango cha 1 EAN | 3471523128330 |
| Masafa Yaliyokadiriwa (f) | Auxiliary Circuit 50 / 60 Hz |
| Kiwango cha Ulinzi | acc. to IEC 60529, IEC 60947-1, EN 60529 Auxiliary Terminals IP10 |
| Kuweka kwenye Reli ya DIN | TH35-15 (35 x 15 mm Mounting Rail) acc. to IEC 60715 |
| Nambari ya Ushuru wa Forodha | 85364900 |
| Vitengo vya Kiwango cha 1 cha Kifurushi | box 1 piece |
| Upana wa Kiwango cha 1 cha Kifurushi | 87 mm |
| Vitengo vya Kiwango cha 2 cha Kifurushi | box 27 piece |
| Upana wa Kiwango cha 2 cha Kifurushi | 250 mm |
| Vitengo vya Kiwango cha 3 cha Kifurushi | 1296 piece |
| Kiasi cha Chini cha Agizo | 1 piece |
| Urefu wa Kifurushi cha Ngazi ya 1 | 47 mm |
| Urefu wa Kifurushi cha Ngazi ya 2 | 315 mm |
| Halijoto ya Hewa ya Mazingira | Close to Contactor Fitted with Thermal O/L Relay -25 ... 60 °C |
| Mchoro wa Vipimo vya CAD | 2CDC001079B0201 |
| Maagizo ya Mwisho wa Maisha | 1SBC101080M6801 |
| Ukadiriaji wa Nguvu za Farasi UL/CSA | (120 V AC) Single Phase 1-1/2 hp |
| Maelekezo na Miongozo | 1SBC101035M6801 |
| Kukaza Torque UL/CSA | Auxiliary Circuit 11 in·lb |
| Ukadiriaji wa Matumizi ya Jumla UL/CSA | (600 V AC) 30 A |
| Uwezo wa Kuvunja Upeo | cos phi=0.45 (cos phi=0.35 for Ie > 100 A) at 440 V 250 A |
| Volti ya Uendeshaji Iliyokadiriwa | Auxiliary Circuit 690 V |
| Idadi ya Mawasiliano Kuu NC | 0 |
| Idadi ya Mawasiliano Kuu HAPANA | 3 |
| Msimbo wa Uainishaji wa Vitu | Q |
| Kina Halisi cha Bidhaa / Urefu | 77 mm |
| Uzito wa Jumla wa Kiwango cha 1 cha Kifurushi | 0.32 kg |
| Uzito wa Jumla wa Kiwango cha 2 cha Kifurushi | 17.28 kg |
| Volti ya Insulation Iliyokadiriwa (Ui) | acc. to IEC 60947-4-1 690 V |
| Azimio la Uzingatiaji - CE | 1SBD250004U1000 |
| Kina / Urefu wa Kiwango cha 1 cha Kifurushi | 79 mm |
| Kina / Urefu wa Kiwango cha 2 cha Kifurushi | 300 mm |
| Azimio la Uzingatiaji - CCC | 2020980304001253 |
| Idadi ya Mawasiliano Saidizi NC | 1 |
| Idadi ya Mawasiliano Saidizi HAPANA | 0 |
| Azimio la Uzingatiaji - UKCA | 1SBD250035U1000 |
| Kiwango cha Juu cha Volti ya Uendeshaji UL/CSA | Main Circuit 600 V |
| Kuweka kwa Skurubu (hazijatolewa) | 2 x M4 screws placed diagonally |
| Nguvu ya Uendeshaji Iliyokadiriwa AC-3 (Pe) | (415 V) 9 kW |
| Nambari ya Kategoria ya Chembechembe ya IDEA (IGCC) | 4758 >> Iec Contactors |
| Volti ya Mzunguko wa Udhibiti Iliyokadiriwa (Uc) | 50 Hz 100 ... 250 V |
| Nguvu ya Uendeshaji Iliyokadiriwa AC-3e (Pe) | (415 V) 9 kW |
| Uendeshaji wa Sasa Uliokadiriwa AC-1 (Yaani) | (690 V) 40 °C 30 A |
| Mkondo wa Uendeshaji Uliokadiriwa AC-3 (Yaani) | (415 V) 60 °C 18 A |
| Uendeshaji wa Sasa Uliokadiriwa DC-1 (Yaani) | (110 V) 1-Pole, 40 °C 20 A |
| Uendeshaji wa Sasa Uliokadiriwa DC-3 (Yaani) | (110 V) 1-Pole, 40 °C 8 A |
| Uendeshaji wa Sasa Uliokadiriwa DC-5 (Yaani) | (110 V) 1-Pole, 40 °C 4 A |
| Sheria ya Kudhibiti Vitu vya Sumu - TSCA | 2CMT2023-006525 |
| Mkondo wa Uendeshaji Uliokadiriwa AC-15 (Yaani) | (500 V) 2 A |
| Uendeshaji wa Sasa Uliokadiriwa AC-3e (Yaani) | (415 V) 60 °C 18 A |
| Uendeshaji wa Sasa Uliokadiriwa DC-13 (Yaani) | (24 V) 6 A / 144 W |
| Masafa ya Juu ya Kubadilisha Umeme | (AC-1) 600 cycles per hour |
| Masafa ya Juu ya Kubadilisha Mitambo | 3600 cycles per hour |
| Urefu wa Juu wa Uendeshaji Unaruhusiwa | Without Derating 3000 m |
| Volti ya Kuhimili Msukumo Iliyokadiriwa (Uimp) | 6 kV |
| Tamko la Bidhaa ya Mazingira - EPD | 1SBD250584E3000 |
| Kiolezo cha Kuripoti Migongano ya Madini (CMRT) | 9AKK108467A5658 |
| Mkondo wa Kawaida wa Joto wa Hewa Isiyolipishwa (Ith) | acc. to IEC 60947-4-1, Open Contactors Θ = 40 °C 35 A |
| Mshtuko na Mtetemo Hustahimili IEC 61373 | Category 1, Class B |
| Imekadiriwa Kuhimili Volti ya Chini ya Mkondo kwa Muda Mfupi (Icw) | at 40 °C Ambient Temp, in Free Air, from a Cold State 10 s 150 A |
Maelezo ya Bidhaa
AF16ZB-30-01RT-23 100-250V50/60HZ-DC Contactor
Vipengele Muhimu
- Ubora wa kiwango cha viwanda
- Inaendana na RoHS
- Imethibitishwa CE
- Dhamana ya mwaka 1
Nyaraka za Bidhaa
Jalada la data
Speci za kiufundi na data ya utendaji
Mwongozo wa Mtumiaji
Mwongozo wa usakinishaji na uendeshaji
